Standard Dial Gauges - 0.001mm and 0.005mm JIS B 7503
Dial Gauges are widely used manufacturing plants.
• The stem, made of SK quench hardened with strength, is malfunction-free due to fastening.
• The shock-proof mechanism prevents gears from damage due to shocks arisen by abruptly pushing up the spindle.
• The turning section of the outer frame sealed by the O-ring and the back inside sealed by the packing are waterproof and dust-proof in construction.
• The back is increased in strength by four screws, and the lug can be turned 90 degrees in the installation way.
Specifications
(unit: μm)
| Order No. | Graduation (mm) |
Range (mm) | Reading | Indication error (MPE) | Hysteresis error |
Repeatability | Measuring force less than (N) |
|||
| 1/10 revolution | 1/2 revolution | One revolution | Whole measuring range |
|||||||
| 5B-HG | 0.001 | 1 | 0 - 100 - 0 | 1.6 | 2.8 | 3.2 | 4 | 1.6 | 0.5 | 1.5 |
| 5-DX | 0.001 | 1 | 0 - 100 - 0 | 2.5 | 3 | 4 | 5 | 3 | 0.5 | 1.5 |
| 5B | 0.001 | 1 | 0 - 100 - 0 | 2 | 3.5 | 4 | 5 | 2 | 0.5 | 1.5 |
| 5F | 0.001 | 1 | 0 - 100 - 0 | 2 | 3.5 | 4 | 5 | 2 | 0.5 | 1.5 |
| 5-SWF | 0.001 | 1 | 0 - 100 - 0 | 2 | 3.5 | 4 | 5 | 2 | 0.5 | 1.5 |
| 25 | 0.001 | 2 | ±0 - 100 - 100 | 2 | 4 | 5 | 7 | 2 | 0.5 | 1.5 |
| 25F-RE | 0.001 | 2 | ±0 - 100 - 100 | 2 | 4 | 5 | 7 | 2 | 0.5 | 1.5 |
| 25S | 0.001 | 2 | 0 - 100 - 0 | 2 | 4 | 5 | 7 | 2 | 0.5 | 1.5 |
| 55 | 0.001 | 5 | 0 - 100 - 0 | 3.5 | 5 | 6 | 10 | 3 | 1 | 1.5 |
| 55-DX | 0.001 | 5 | 0 - 100 - 0 | 3.5 | 5 | 6 | 10 | 3 | 1 | 1.5 |
| 56 | 0.005 | 5 | 0 - 25 - 50 | 5 | 9 | 10 | 12 | 3 | 3 | 1.5 |
| แบรนด์สินค้า | PEACOCK |
|---|
Standard 0.001mm 0.005mm
mm
| Order No. | A | B | C | D | E | F | G | H | I | J | |
| 5B-HG | 60 | 41.5 | 18.5 | 53 | 14.5 | 20 | 4 | 6.5 | 49 | 8.0 | 0 –0.022 |
| 5-DX | 60 | 42.6 | 17 | 55.7 | 14.5 | 20 | 5 | 7 | 52 | 8.0 | 0 –0.03 |
| 5B | 60 | 41.5 | 18.5 | 53 | 14.5 | 20 | 4 | 6.5 | 49 | 8.0 | 0 –0.022 |
| 5F | 60 | 41.5 | 18.5 | 53 | 14.5 | - | 4 | 6.5 | 49 | 8.0 | 0 –0.022 |
| 5-SWF | 63 | 41.5 | 17.5 | 55 | 15 | 20 | 4 | 6.5 | 49 | 8.0 | 0 –0.022 |
| 25 | 72 | 42 | 25 | 66.5 | 14.5 | 20 | 4 | 7.5 | 62.5 | 8.0 | 0 –0.03 |
| 25F-RE | 72 | 41 | 25 | 66.5 | 14.5 | - | 4 | 7.5 | 62.5 | 8.0 | 0 –0.03 |
| 25S | 60 | 42.6 | 17 | 55.7 | 14.5 | 20 | 5 | 7 | 52 | 8.0 | 0 –0.03 |
| 55 | 73 | 52 | 25 | 66 | 17 | 20 | 4.5 | 7 | 62.5 | 8.0 | 0 –0.03 |
| 55-DX | 62 | 44.5 | 17 | 57 | 17 | 19.5 | 4.5 | 6.5 | 52 | 8.0 | 0 –0.03 |
| 56 | 62 | 44.5 | 17 | 57 | 17 | 19.5 | 4.5 | 6.5 | 52 | 8.0 | 0 –0.03 |
