STEEL PIN GAUGE SET - AAP SEIRES | SK NIIGATASEIKI
ราคาต่ำสุด
THB 0.00
พร้อมส่ง
SKU
SK-AAP
FEATURES
● Pin gauge set consists of frequently used sizes
● Same specifications as AA series
● Custom made pin gauge sets are available on request
●With certificate of compliance
● Individual pin gauges are also available
（plastic case included）
※ Pin Vise is not included
（0.010mm step）
Consist of intermediate nominal size pin gauges of AA Series
| Order No. | Model No. | Nominal size （mm） |
Pin per set |
Weight （Including case） |
| 201302 | AAP-0B | 0.505 ・ 0.515 ・ 0.525… 1.005 | 51 | 0.99kg |
| 201311 | AAP-1A | 1.005 ・ 1.015 ・ 1.025… 1.505 | 51 | 1.00kg |
| 201312 | AAP-1B | 1.505 ・ 1.515 ・ 1.525… 2.005 | 51 | 1.03kg |
| 201321 | AAP-2A | 2.005 ・ 2.015 ・ 2.025… 2.505 | 51 | 1.06kg |
| 201322 | AAP-2B | 2.505 ・ 2.515 ・ 2.525… 3.005 | 51 | 1.10kg |
| 201331 | AAP-3A | 3.005 ・ 3.015 ・ 3.025… 3.505 | 51 | 1.15kg |
| 201332 | AAP-3B | 3.505 ・ 3.515 ・ 3.525… 4.005 | 51 | 1.20kg |
| 201341 | AAP-4A | 4.005 ・ 4.015 ・ 4.025… 4.505 | 51 | 1.26kg |
| 201342 | AAP-4B | 4.505 ・ 4.515 ・ 4.525… 5.005 | 51 | 1.34kg |
| 201351 | AAP-5A | 5.005 ・ 5.015 ・ 5.025… 5.505 | 51 | 1.42kg |
| 201352 | AAP-5B | 5.505 ・ 5.515 ・ 5.525… 6.005 | 51 | 1.50kg |
| 201361 | AAP-6A | 6.005 ・ 6.015 ・ 6.025… 6.505 | 51 | 1.60kg |
| 201362 | AAP-6B | 6.505 ・ 6.515 ・ 6.525… 7.005 | 51 | 2.08kg |
| 201371 | AAP-7A | 7.005 ・ 7.015 ・ 7.025… 7.505 | 51 | 2.29kg |
| 201372 | AAP-7B | 7.505 ・ 7.515 ・ 7.525… 8.005 | 51 | 2.41kg |
| 201381 | AAP-8A | 8.005 ・ 8.015 ・ 8.025… 8.505 | 51 | 2.54kg |
| 201382 | AAP-8B | 8.505 ・ 8.515 ・ 8.525… 9.005 | 51 | 2.67kg |
| 201391 | AAP-9A | 9.005 ・ 9.015 ・ 9.025… 9.505 | 51 | 2.81kg |
| 201392 | AAP-9B | 9.505 ・ 9.515 ・ 9.525… 10.005 | 51 | 2.97kg |
| แบรนด์สินค้า | NIIGATA SEIKI (SK) |
|---|
