STEEL PIN GAUGE SET WITH HANDLE AG SERIES
Available from 1pc. Handle enables indirect contact with hand and gauge to avoid thermal expansion.
SUB-ZERO（Cryogenic hardened）TREATMENT
※ 2,700mm or over
FEATURES
● AA series Pin Gauge with plastic handle
● Easy to handle for measuring
● Less affected by temperature
● The handle protects Pin Gauges from skin oil and salts
● Size is marked on each plastic handle
● With certificate of compliance
● Individual pin gauges are also available
SPECIFICATIONS
［Standard stock］
| Nominal size （mm） |
Step （mm） |
Length（mm） | Tolerance （μm） |
Out of Roundness （μm） |
Diameter Inequality （μm） |
Hardness （HV） |
|
| Gauge Length | Overall Length | ||||||
| 0.07… 0.09 | 0.01 step | 3 | 41 | ± 0.5 | 0.5 | 0.5 | More than 720 |
| 0.10… 0.29 | ± 0.8 | 0.8 | |||||
| 0.30… 0.49 | 10 | 48 | |||||
| 0.50… 0.99 | 20 | 58 | |||||
| 1.00… 2.69 | 30 | 71 | |||||
| 2.70… 5.00 | More than 650 |
||||||
| 5.01…10.00 | 76 | ||||||
※ Exceptionally, for 1.00mm Pin Gauge in Set No. AG-0B -- Gauge Length: 20mm / Overall Length: 58mm
※ 5mm from each edge is not precision guaranteed (Length 30mm over)
（0.01mm step）
| SK - Order No. | Model No. | Nominal size （mm） |
Pins per set |
Weight （Including case） |
| 203001 | AG-0A | 0.20・0.21・0.22… 0.50 | 31 | 0.92kg |
| 203002 | AG-0B | 0.50・0.51・0.52… 1.00 | 51 | 0.99kg |
| 203011 | AG-1A | 1.00・1.01・1.02… 1.50 | 51 | 1.08kg |
| 203012 | AG-1B | 1.50・1.51・1.52… 2.00 | 51 | 1.10kg |
| 203021 | AG-2A | 2.00・2.01・2.02… 2.50 | 51 | 1.13kg |
| 203022 | AG-2B | 2.50・2.51・2.52… 3.00 | 51 | 1.17kg |
| 203031 | AG-3A | 3.00・3.01・3.02… 3.50 | 51 | 1.22kg |
| 203032 | AG-3B | 3.50・3.51・3.52… 4.00 | 51 | 1.28kg |
| 203041 | AG-4A | 4.00・4.01・4.02… 4.50 | 51 | 1.34kg |
| 203042 | AG-4B | 4.50・4.51・4.52… 5.00 | 51 | 1.41kg |
| 203051 | AG-5A | 5.00・5.01・5.02… 5.50 | 51 | 1.82kg |
| 203052 | AG-5B | 5.50・5.51・5.52… 6.00 | 51 | 1.91kg |
| 203061 | AG-6A | 6.00・6.01・6.02… 6.50 | 51 | 2.00kg |
| 203062 | AG-6B | 6.50・6.51・6.52… 7.00 | 51 | 2.10kg |
| 203071 | AG-7A | 7.00・7.01・7.02… 7.50 | 51 | 2.21kg |
| 203072 | AG-7B | 7.50・7.51・7.52… 8.00 | 51 | 2.33kg |
| 203081 | AG-8A | 8.00・8.01・8.02… 8.50 | 51 | 2.51kg |
| 203082 | AG-8B | 8.50・8.51・8.52… 9.00 | 51 | 2.64kg |
| 203091 | AG-9A | 9.00・9.01・9.02… 9.50 | 51 | 2.79kg |
| 203092 | AG-9B | 9.50・9.51・9.52… 10.00 | 51 | 2.94kg |
Sizes available： 0.07 〜10.00mm（Please contact us with request）
