STEEL STRAIGHT EDGE - OS-141 Class B | OHNISHI (O.S.S)
ราคาต่ำสุด
THB 0.00
พร้อมส่ง
SKU
OSS-OS141B
Features
• Material : S50C
• This item is mainly to be used in marking work of machine technician.
• Material is soft steel and ground for standard type high precision finish of toolsteel and lapped is also available at you option. (Heat treatment is acceptable if required)
• Straightness Class B - (20 + L 25 ) µm L= Nominal size
• Straightness Class A - (10 + L 50 ) µm L= Nominal size
• Without heat treatment
• Hardened : Hv490(Hs65) ~ Hv620(Hs75)
Bevel type dimension OS-141
| Order No. | Nominal Size (mm) | Size (mm) | Weight (kg) |
| Class B | L x H x W | ||
| 141-150B | 150 | 150 x 24 x 3 | 0.06 |
| 141-200B | 200 | 200 x 24 x 3 | 0.11 |
| 141-250B | 250 | 250 x 30 x 4 | 0.24 |
| 141-300B | 300 | 300 x 35 x 5 | 0.42 |
| 141-450B | 450 | 450 x 40 x 5 | 0.72 |
| 141-500B | 500 | 500 x 40 x 5 | 0.8 |
| 141-600B | 600 | 600 x 40 x 6 | 0.9 |
| 141-750B | 750 | 750 x 45 x 6 | 1.5 |
| 141-900B | 900 | 900 x 50 x 6 | 2.4 |
| 141-1000B | 1000 | 1000 x 50 x 6 | 2.6 |
| 141-1200B | 1200 | 1200 x 65 x 7.5 | 4 |
| 141-1500B | 1500 | 1500 x 75 x 8 | 5.8 |
| 141-1800B | 1800 | 1800 x 80 x 8 | 9.2 |
| 141-2000B | 2000 | 2000 x 85 x 10 | 11.7 |
| 141-2500B | 2500 | 2500 x 95 x 11 | 19 |
| 141-3000B | 3000 | 3000 x 95 x 11 | 24 |
| 141-3500B | 3500 | 3500 x 100 x 11 | 28.1 |
| 141-4000B | 4000 | 4000 x 100 x 11 | 35.2 |
| 141-5000B | 5000 | 5000 x 110 x 12 | 52.8 |
| แบรนด์สินค้า | OHNISHI (O.S.S.) |
|---|
