STRAIGHT EDGE WITH KNUFE SHAPED EDGE - OS-133 | OHNISHI (O.S.S)
สินค้าหมด
SKU
OSS-OS133
Features
• This item is used to measure the parallelism accurately by line contacting withworkpiece and very thin edge.
• A knife-shaped edge can give easy inspection for narrow corners
• Meterial - Carbon tool steel
• Squareness - (20 + L 250 ) µm L=Overall length
• Hardened - Hv490 (Hs65) ~ Hv620 (Hs75)
Dimensions (with fittings) OS-133
| Order No. | Overall length (mm) | Width (mm) | Weight (kg) |
| 133-75 | 75 | 23 | 0.06 |
| 133-80 | 80 | 23 | 0.074 |
| 133-100 | 100 | 24 | 0.16 |
| 133-125 | 125 | 25 | 0.19 |
| 133-150 | 150 | 28 | 0.24 |
| 133-175 | 175 | 30 | 0.31 |
| 133-200 | 200 | 30 | 0.32 |
| 133-250 | 250 | 32 | 0.4 |
| 133-300 | 300 | 35 | 0.63 |
| 133-400 | 400 | 40 | 0.9 |
| 133-500 | 500 | 40 | 1.5 |
| แบรนด์สินค้า | OHNISHI (O.S.S.) |
|---|
