SU-PO22X1.5 (PUMS022O) | Spiral Pointed Taps for Stainless Steels | YAMAWA

เป็นคนแรกที่รีวิวสินค้านี้

ราคาพิเศษ THB 0.00 ราคาปรกติ THB 2,527.00

*ราคายังไม่รวม VAT

พร้อมส่ง

SKU

PUMS022O

QTY:

Product Features

The SU+PO/SU-PO taps are designed for stainless steel that causes work harden easily. The cutting geometry is also suited for tapping through holes in chromium steel and molybdenum steel.
To prevent chip welding, the tap's surface is oxidized.

Comparison chart

Skip to the end of the images gallery

Skip to the beginning of the images gallery

SU-PO22X1.5 (PUMS022O) | Spiral Pointed Taps for Stainless Steels | YAMAWA

Details

Specification

Tapping Speeds depending on Materials

・Product Name and Size.

SU＋PO	〜M2.6
SU−PO	M3〜, all U, all W

Oversize

Segment：1E

Size	Class	Code	Chamfer	L (mm)	ℓ (mm)	ℓn (mm)	ℓs (mm)	Ds (mm)	K (mm)	ℓk (mm)	No. of flutes	TYPE
For Metric Threads
M3×0.5	P2	PUMQ3.0G	5P	46	9	14	26	4	3.2	6	3	3
M3×0.5	P3	PUMR3.0G	5P	46	9	14	26	4	3.2	6	3	3
M3×0.5	P4	PUMS3.0G	5P	46	9	14	26	4	3.2	6	3	3
3M0.6	P2	PUMQ3.0H	5P	46	9	14	26	4	3.2	6	3	3
M3.5×0.6	P2	PUMQ3.5H	5P	52	11	16	29	5	4	7	3	3
M4×0.7	P2	PUMQ4.0I	5P	52	11	17	29	5	4	7	3	3
M4×0.7	P3	PUMR4.0I	5P	52	11	17	29	5	4	7	3	3
M4×0.7	P4	PUMS4.0I	5P	52	11	17	29	5	4	7	3	3
4M0.75	P2	PUMQ4.0J	5P	52	11	17	29	5	4	7	3	3
M5×0.8	P2	PUMQ5.0K	5P	60	13	22	33	5.5	4.5	7	3	3
M5×0.8	P3	PUMR5.0K	5P	60	13	22	33	5.5	4.5	7	3	3
M5×0.8	P4	PUMS5.0K	5P	60	13	22	33	5.5	4.5	7	3	3
5M0.9	P2	PUMQ5.0L	5P	60	13	22	33	5.5	4.5	7	3	3
M6×1	P2	PUMQ6.0M	5P	62	15	26	33	6	4.5	7	3	3
M6×1	P3	PUMR6.0M	5P	62	15	26	33	6	4.5	7	3	3
M6×1	P4	PUMS6.0M	5P	62	15	26	33	6	4.5	7	3	3
M6×0.75	P2	PUMQ6.0J	5P	62	15	26	33	6	4.5	7	3	3
M7×1	P2	PUMQ7.0M	5P	70	19	-	36	6.2	5	8	3	4
M8×1.25	P3	PUMR8.0N	5P	70	19	-	36	6.2	5	8	3	4
M8×1.25	P4	PUMS8.0N	5P	70	19	-	36	6.2	5	8	3	4
M8×1.25	P5	PUMT8.0N	5P	70	19	-	36	6.2	5	8	3	4
M8×1	P3	PUMR8.0M	5P	70	19	-	36	6.2	5	8	3	4
M10×1.5	P3	PUMR010O	5P	75	23	-	38	7	5.5	8	3	4
M10×1.5	P4	PUMS010O	5P	75	23	-	38	7	5.5	8	3	4
M10×1.5	P5	PUMT010O	5P	75	23	-	38	7	5.5	8	3	4
M10×1.25	P3	PUMR010N	5P	75	23	-	38	7	5.5	8	3	4
M10×1.25	P4	PUMS010N	5P	75	23	-	38	7	5.5	8	3	4
M10×1	P3	PUMR010M	5P	75	23	-	38	7	5.5	8	3	4
M12×1.75	P4	PUMS012P	5P	82	26	-	42	8.5	6.5	9	3	4
M12×1.75	P5	PUMT012P	5P	82	26	-	42	8.5	6.5	9	3	4
M12×1.5	P3	PUMR012O	5P	82	26	-	42	8.5	6.5	9	3	4
M12×1.5	P5	PUMT012O	5P	82	26	-	42	8.5	6.5	9	3	4
M12×1.25	P4	PUMS012N	5P	82	26	-	42	8.5	6.5	9	3	4
M12×1.25	P5	PUMT012N	5P	82	26	-	42	8.5	6.5	9	3	4
M12×1	P3	PUMR012M	5P	82	26	-	42	8.5	6.5	9	3	4
M14×2	P4	PUMS014Q	5P	88	26	-	45	10.5	8	11	3	4
M14×2	P5	PUMT014Q	5P	88	26	-	45	10.5	8	11	3	4
M14×1.5	P3	PUMR014O	5P	88	26	-	45	10.5	8	11	3	4
M14×1.5	P5	PUMT014O	5P	88	26	-	45	10.5	8	11	3	4
M14×1	P3	PUMR014M	5P	88	26	-	45	10.5	8	11	3	4
M15×1.5	P3	PUMR015O	5P	95	26	-	48	12.5	10	13	3	4
M15×1	P3	PUMR015M	5P	95	26	-	48	12.5	10	13	3	4
M16×2	P4	PUMS016Q	5P	95	26	-	48	12.5	10	13	3	4
M16×2	P5	PUMT016Q	5P	95	26	-	48	12.5	10	13	3	4
M16×2	P6	PUMU016Q	5P	95	26	-	48	12.5	10	13	3	4
M16×1.5	P3	PUMR016O	5P	95	26	-	48	12.5	10	13	3	4
M16×1.5	P5	PUMT016O	5P	95	26	-	48	12.5	10	13	3	4
M16×1	P3	PUMR016M	5P	95	26	-	48	12.5	10	13	3	4
M18×2.5	P4	PUMS018R	5P	100	33	-	51	14	11	14	3	4
M18×2.5	P5	PUMT018R	5P	100	33	-	51	14	11	14	3	4
M18×2.5	P6	PUMU018R	5P	100	33	-	51	14	11	14	3	4
M18×1.5	P4	PUMS018O	5P	100	33	-	51	14	11	14	3	4
M18×1.5	P5	PUMT018O	5P	100	33	-	51	14	11	14	3	4
M20×2.5	P4	PUMS020R	5P	105	33	-	50	15	12	15	3	5
M20×2.5	P5	PUMT020R	5P	105	33	-	50	15	12	15	3	5
M20×2.5	P6	PUMU020R	5P	105	33	-	50	15	12	15	3	5
M20×1.5	P4	PUMS020O	5P	105	33	-	50	15	12	15	3	5
M20×1.5	P5	PUMT020O	5P	105	33	-	50	15	12	15	3	5
M22×2.5	P4	PUMS022R	5P	115	33	-	55	17	13	16	3	5
M22×2.5	P5	PUMT022R	5P	115	33	-	55	17	13	16	3	5
M22×2.5	P6	PUMU022R	5P	115	33	-	55	17	13	16	3	5
M22×1.5	P4	PUMS022O	5P	115	33	-	55	17	13	16	3	5
M22×1.5	P5	PUMT022O	5P	115	33	-	55	17	13	16	3	5
M24×3	P4	PUMS024S	5P	120	39	-	55	19	15	18	3	5
M24×3	P5	PUMT024S	5P	120	39	-	55	19	15	18	3	5
M24×3	P6	PUMU024S	5P	120	39	-	55	19	15	18	3	5
M24×1.5	P4	PUMS024O	5P	120	39	-	55	19	15	18	3	5
M27×3	P4	PUMS027S	5P	130	39	-	60	20	15	18	4	5
M27×1.5	P4	PUMS027O	5P	130	39	-	60	20	15	18	4	5
M30×3.5	P5	PUMT030T	5P	135	46	-	62	23	17	20	4	5
M30×1.5	P4	PUMS030O	5P	135	46	-	62	23	17	20	4	5
M33×3.5	P5	PUMT033T	5P	145	46	-	67	25	19	22	4	5
M36×4	P5	PUMT036U	5P	155	52	-	71	28	21	24	4	5
M39×4	P5	PUMT039U	5P	165	52	-	76	30	23	26	4	5
M42×4.5	P5	PUMT042V	5P	175	59	-	81	32	26	30	4	5

More Information

ข้อมูลเพิ่มเติม
แบรนด์สินค้า	YAMAWA
Order No.	M22x1.5 (PUMS022O)
Model	SU+PO/ SU-PO
Size	M22X1.5
Class	P4
Chamfer	5P
Overall length (L)	115
Thread length (ℓ)	33
Thread + Neck length (ℓn)	-
Shank length (ℓs)	55
Shank dia. (Ds)	17
Size of Square (K)	13
Length of square (ℓk)	16

Dimension
