SV-55CB-50R1 | Universal Testing Machine | IMADA SEISAKUSHO

Features
SV-55BC is an electrically operated desktop type tensile testing machine. The value of load is
measured by loadcell. Maximum load for this type (model) is 500N.
■ Characteristics
○ Compared to combinations of Digital Force Gauge and Stand, this testing machine is
inexpensive, and it can be measured with simple operation. However, it has the functions
according to the UTM such as overload protection and software.
○ This testing machine is about 30% smaller and lighter than the previous model.
So, you do not have to worry about that place.
○ It can prepare loadcell from 20N to 500N. Therefore, you can choose the one suitable for what
you want to measure. In addition, if the 2 range specification type, it will be expanded the
measurement range.
■Usage example
○ Peeling tests of the adhesion and the heat seal.
○ Tensile tests of solderless terminal.
○ Various kinds of test such as foods or medical supplies.
■Options
○ Long Axis /150mm longer axis than the standard.
○ Special Speed type (5～120mm/min)
○ Printer Output (for Digimatic Printer) *2
○ Date Processing Software ‘Facirec’

Standard Specifications

※1The model symbol is put in □. Refer to [Combination of Load Range According to the Model]

※2 Digimatic printer output can be installed with additional option.

※3 The listed 'height' is measured with lower condition of 'UP/DOWN axis'

Specifications of Load Range

※1　The usable range is recommended at 20~100% of each setting Load Range.

Combination of Load Range according to the model
