SVL/SVH-1000N | Simple Type Manual Test Stand | IMADA
ราคาต่ำสุด
THB 0.00
THB 0.00
ราคาปรกติ
THB 26,386.20
พร้อมส่ง
SKU
IMA-SVL/SVH-1000N
- Manual test stand SVL series is simple type offering excellent cost performance with 1000N capacity. Its lever operation improves measuring efficiency.
- Manual test stand SVH series is simple type offering excellent cost performance with 1000N capacity. Its handle operation offers stable measurement.
Features
- Achieve precision measurement with constant testing angle
- Improves measuring efficiency with its lever operation
- Allows testing where you need it due to its light-weight and compact design, requiring only a space of A4-sized paper
- Handles a wide range of testing applications to meet your requirements with options such as -S (length scale) and -EXT (Extended column)
Specifications
| Order No. | SVL-1000N | SVH-1000N |
| Capacity | 1000N | |
| Force direction | Tension and compression | |
| Travel method | Lever | Handle |
| Travel per 1 turn | 60mm per 170 degrees | 3 mm |
| Max. Sample Height *1 | Approx. 225mm | |
| Stroke | 60 mm | |
| Function | Mechanical stopper | |
| Weight | Approx. 7.3 kg | Approx. 7.7 kg |
| Dimension | Approx. W200 x D280 x H410mm | |
| Fixable force gauge *2 | Digital force gauge: DST, DSV, ZTS, ZTA series Mechanical force gauge: FB, PS, PSM series | |
*1 The Max. Sample Height refers to the distance between the test stand table and the tip of force gauge (1000N or less of ZT series) measuring shaft when the head is at the top.
*2 Some high capacity model force gauges (with M10 thread) and load cells cannot be mounted to the test stand. Please check the dimensions before purchase.
| แบรนด์สินค้า | IMADA |
|---|---|
| Order No. | SVL/SVH-1000N |
