TAGLENS-T1 | Varifocal Lens | MITUTOYO
THB 0.00
THB 0.00
พร้อมส่ง
SKU
TAGLENS-T1
Varifocal Lens
TAGLENS-T1
Captures a clear image with a deep depth of focus by adjusting the focal length at a high speed.
Ultra-high-speed varifocal lens.
A dedicated controller and a control software TAGPAK-C are offered as a standard product.
Resonance frequency: 70 kHz
Effective aperture: ø11 mm
TAGLENS main unit
| Resonance frequency | 70 kHz |
| Effective aperture | ø11 mm |
| Transmittance | 90% or more (λ400 nm to 700 nm) |
| Max. amplitude of optical power | 1 D (total range 2D) |
| Min. amplitude of optical power | 0.7 D (total range 1.4D) |
| Mounting angle | Any |
| Guaranteed operational temperature range | 15 ℃ to 30 ℃ |
| Operating Environment / Humidity | 10 ℃ to 40 ℃ / 40% to 70% RH (non-condensing) |
| Storage Environment / Humidity | -10 ℃ to 50 ℃ / 80% RH or less (non-condensing) |
| Mass | Approx. 0.6 kg |
Controller
| Dimensions（ W×D×H） | 144.2 mm × 107 mm × 51.2 mm |
| Mass | Approx. 0.4 kg |
| Input | +12V (Attached AC adapter) |
| Power supply voltage | AC 100 V to 240 V 50 Hz / 60 Hz |
| Power consumption | Max. 20 W |
| แบรนด์สินค้า | MITUTOYO |
|---|---|
| Order No. | TAGLENS-T1 |
