TENSION GAUGE - ROD TYPE
- A round spring-type tension gauge is a gauge that represents the scale on a cylindrical shape and measures it accurately by applying the force of a spring when measuring pressing force, pulling force, plate spring, etc. We also manufacture special products.
- Standard type for left side is generally used type, but when it is used in horizontal condition, add horizontal error to actual measurement value.
Please. When using reverse vertical, it will be double the horizontal time error.
Accuracy: ±1 scale
| Order No. | Model | Instrument Type (N) | First sight (N) | Horizontal error (N) | Gross weight (g) |
| U-0114-0001 | O-BT | 0.1 | 0.005 | 0.04 | 40 |
| U-0114-0002 | 0.3 | 0.01 | 0.04 | 45 | |
| U-0114-0003 | 0.5 | 0.01 | 0.1 | 45 | |
| U-0114-0004 | 1 | 0.025 | 0.1 | 50 | |
| U-0114-0005 | 2 | 0.05 | 0.1 | 50 | |
| U-0114-0006 | 3 | 0.075 | 0.1 | 50 | |
| U-0114-0007 | 5 | 0.125 | 0.35 | 100 | |
| U-0114-0008 | 6 | 0.2 | 0.35 | 100 | |
| U-0114-0009 | 10 | 0.25 | 0.35 | 100 | |
| U-0114-0010 | 15 | 0.5 | 0.35 | 100 | |
| U-0114-0011 | 20 | 0.5 | 0.35 | 100 | |
| U-0114-0012 | 25 | 0.5 | 0.5 | 150 | |
| U-0114-0013 | 30 | 0.75 | 0.5 | 150 | |
| U-0114-0014 | 40 | 1 | 1 | 250 | |
| U-0114-0015 | 50 | 1 | 1 | 250 | |
| U-0114-0016 | 70 | 2 | 1 | 250 | |
| U-0114-0017 | 100 | 2 | 1 | 250 | |
| U-0114-0018 | 150 | 2 | 2.5 | 500 | |
| U-0114-0019 | 200 | 2 | 2.5 | 650 | |
| U-0114-0020 | 300 | 3 | 3.5 | 950 | |
| U-0114-0021 | 500 | 5 | 3.5 | 950 | |
| U-0114-0022 | 1000 | 10 | 3.5 | 1200 |
| แบรนด์สินค้า | OBA |
|---|
