THICK TYPE SQUARE - OS-150 | OHNISHI (O.S.S)
ราคาต่ำสุด
THB 0.00
พร้อมส่ง
SKU
OSS-OS150
Features
Squareness : ± (10 + L 20 ) µm “L” is the nominal size
• Application
- Precision measurement of the squareness of products and parts
• Features
- Since this square is thicker than ordinary products, you can make a solid contact with the object being checked.
- Hardened
• Materials
- Carbon tool steel
- Quenching hardness HV450 (HS60) or more
Dimensions OS-150
| Order No. | Nominal Size (mm) | Size (mm) | Weight (kg) | |||
| Overall length, long side | Overall length, short side | Width | Thickness | |||
| 150-50 | 50 | 50 | 30 | 12 | 8 | 0.1 |
| 150-75 | 75 | 75 | 50 | 15 | 8 | 0.2 |
| 150-100 | 100 | 100 | 70 | 20 | 10 | 0.3 |
| 150-125 | 125 | 125 | 85 | 20 | 10 | 0.4 |
| 150-150 | 150 | 150 | 100 | 25 | 15 | 0.8 |
| 150-200 | 200 | 200 | 130 | 25 | 15 | 1.0 |
| 150-250 | 250 | 250 | 165 | 30 | 15 | 1.8 |
| 150-300 | 300 | 300 | 200 | 35 | 20 | 3.2 |
| แบรนด์สินค้า | OHNISHI (O.S.S.) |
|---|
