TOK-G DIAL INDICATOR TORQUE WRENCHES | KANON
ราคาต่ำสุด
THB 0.00
พร้อมส่ง
SKU
KAN-TOK-G
FEATURES
● Oval design with comfort rubber grip reduces strain.
● Easily readable for inspections.
● Useful for general tightening work.
● Accuracy : ±3% of indicated value over the full range.
USING A TOK WRENCH
(1) Turn the dial cap and set the indicator to 0.
(2) Mount a socket on the square drive.
(3) Tighten until the indicator points to the desired torque.
* When using a peak indicator wrench, set it to 0 before tightening.
| Order No. (kgf•cm / kgf•m) | Range (CW/CCW) | Increment | Order No. (N•m) | Range (CW/ CCW) | Increment |
Square drive | Total length | Dimensions (mm) | Weight | ||||||
| Head | Body | ||||||||||||||
| kgf•cm / kgf•m | N•m |
mm | S | A | B | C | D | E | F | G | kg | ||||
| 60TOK-G | 6~60 kgf•cm | 1 kgf•cm | N 6TOK-G | 0.6~6 | 0.1 | 6.35 (1/4”) |
260 | 35 | 38.5 | 7.5 | 58 | 90 | 37 | 21.5 | 0.5 |
| 120TOK-G | 10~120 kgf•cm | 2 kgf•cm | N 12TOK-G | 1~12 | 0.2 | ||||||||||
| 300TOK-G | 50~300 kgf•cm | 5 kgf•cm | N 30TOK-G | 5~30 | 0.5 | 9.53 (3/8”) |
323 | 35 | 43 | 11 | 60 | 90 | 37 | 21.5 | 0.61 |
| 500TOK-G | 50~500 kgf•cm | 5 kgf•cm | N 50TOK-G | 5~50 | 0.5 | ||||||||||
| 700TOK-G | 100~700 kgf•cm | 10 kgf•cm | N 70TOK-G | 10~70 | 1 | ||||||||||
| 1400TOK-G | 200~1,400 kgf•cm | 20 kgf•cm | N 140TOK-G | 20~140 | 2 | 12.7 (1/2”) |
463 | 39 | 49 | 14 | 65 | 90 | 41 | 22.5 | 0.87 |
| 2000TOK-G | 200~2,000 kgf•cm | 20 kgf•cm | N 200TOK-G | 20~200 | 2 | ||||||||||
| 3000TOK-G | 3~30 kgf•m | 0.5 kgf•m | N 300TOK-G | 30~300 | 5 | 19.05 (3/4”) |
682 | 41 | 55 | 20 | 77 | 90 | Ø30 | Ø30 | 1.6 |
| 4200TOK-G | 4~42 kgf•m | 1 kgf•m | N 420TOK-G | 40~420 | 10 | 955 | 48 | 60 | Ø34 | Ø34 | 2.5 | ||||
| 5500TOK-G | 5~55 kgf•m | 1 kgf•m | N 550TOK-G | 50~550 | 10 | 1,110 | 50 | 80 | Ø38 | Ø30 | 3.8 | ||||
| แบรนด์สินค้า | KANON |
|---|
