TORQUE TESTER - DIS-IP series (-IP05/5/50/200/500) | CEDAR
ราคาต่ำสุด
THB 0.00
พร้อมส่ง
SKU
CEDAR-DIS-IP
Suitable for managing various manual torque wrench & torque drivers
Standard model for static torque measurement
Bigger characters size and enhance user convenience.
Enable to be installed in a small space due to a separate type.
Enable to save 5 channels of pass/fail judgement criterion, and enable to change settings easily by switch channels even if the tightening term changes.
• Show “Measurement mode” “Measurement unit” Indication of “maximum, minimum, average”
• Switchable measurement unit
• Enable to save 5 sets of settings such as upper limit and lower limit
• 800 items of memory data
• Real-time output About every 1/180 seconds
• Data acquisition software can be downloaded for free
| Order No. | DIS-IP05 | DIS-IP5 | DIS-IP50 | DIS-IP200 | DIS-IP500 |
| Measurement range | 2.0 ~ 500m N•m 0.020 ~ 5 kgf•cm 0.020 ~ 45 lbf•in | 0.020 ~ 5 N•m 0.20 ~ 50 kgf•cm 0.20 ~ 45 lbf•in | 0.20 ~ 50 N•m 2.0 ~ 500 kgf•cm 2.0 ~450 lbf•in | 2.0 ~ 200N•m20 ~ 2000 kgf•cm 20 ~ 1740 lbf•in | 2.0 ~ 500 N•m 20 ~ 5000 kgf•cm 20 ~4500 lbf•in |
| Accuracy | ±0.5% (499 digit or less ±1digit) | ||||
| Display | The 4 figures digital display of LCD | ||||
| The measurement direction | CW-CCW (right and left) | ||||
| Mode | P-P | The highest value of load is hold-displayed | |||
| T-R | A display also changes with load change. | ||||
| P-D | Load catches and displays the moment included in descent from a rise. | ||||
| C | Load torque value is outputted every about 1/180 second | ||||
| Clearance | It is a display clearance in set-up time (0.1-3.0sec) | ||||
| A success or failure judging function |
High and low value are measurement within the limits, and can be set up. Five-set preservation is possible. |
||||
| The Maximum, the minimum, and the average value | Displays, and output the data number, the maximum, the minimum, and the average value of the measured value. | ||||
| Data memory counts | 800 data | ||||
| Auto-Power-off | After the neglect during 10 minutes | ||||
| Data output | ASCII format (baud rate 19200) | ||||
| Power supply | Ni-Cd chargeable battery 1.2Vx5cells 700mAh | ||||
| Charge time / use time | Charge about 3 hour / Continuation about 12-hour use | ||||
| indicator size / weight | 100(W) x 105(D) x 33(H) (it does not contain by the projection thing) / 357g | ||||
| Code length | Standard 1m (there are automatic machines no less than 4m as an option) | ||||
| Accessories | AC/DC adaptor | ||||
| An inspection report, a proofreading certificate, a traceability system figure | |||||
Detection machine size figure
| Form | IP05 | IP5 | IP50 | IP200 | IP500 | Detection machine outside figure |
| A | Ø 40 | Ø60 | Ø60 | Ø60 |  |
|
| B | 41.2 | 63 | 79 | 99 | ||
| C | 5 | 10 | 15 | 15.5 | ||
| D | Ø60 | Ø90 | Ø110 | Ø140 | ||
| E | Ø60 | Ø74 | Ø90 | Ø116 | ||
| F (Three division) | Ø4.5 | Ø6.5 | Ø8.3 | Ø10.5 | ||
| G (Socket intuition affinity) | 6.35sq | 9.5sq | 12.7sq | 19sq | ||
| Weight | 189g | 632g | 1.8kg | 3.5kg | ||
| แบรนด์สินค้า | CEDAR |
|---|
