TPD-617A | Digital Pipe Gauge | TECLOCK
THB 0.00
*ราคายังไม่รวม VAT
พร้อมส่ง
SKU
TPD-617A
QTY:
10
Digital Pipe Gauge
Specifications
| Order No. | Graduation (mm) |
Measuring Range(mm) |
Indication Error(μm) | Parallelism (μm) |
Measuring Force(N) |
Contact Point Form(mm) |
Anvil Form (mm) |
Weight (g) |
| TPD-617A | 0.01 | 12 | ±20 | - | 1.5 | φ1.6 Ball | φ0.5,1.0,2.0 replaceable | 255 |
| TPD-618A | 0.01 | 12 | ±20 | - | 1.5 | φ1.6 Ball | φ5.0 (φ 7.0,10.0) replaceable* | 260 |
*Anvils of φ7 and φ10.0 are optional.
| แบรนด์สินค้า | TECLOCK |
|---|---|
| Order No. | TPD-617A |
| Graduation | 0.01mm |
Relation between Anvil diameter and Work inserting depth
unit : mm
| Anvil dia. | Depth | Anvil dia. | Depth | |
| φ0.5 | 2 | φ5.0 | 8 | |
| φ1.0 | 3 | φ7.0 | 8 | |
| φ2.0 | 3 | φ10.0 | 8 |
