UKT-100N | Built-in Use Model Mechanical Force Gauge | IMADA
ราคาพิเศษ
THB 0.00
ราคาปรกติ
THB 11,121.50
*ราคายังไม่รวม VAT
สินค้าหมด
SKU
UKT-100N
QTY:
0
Integration type mechanical force gauge has capacity of 300N. They are compact and ideal for integration into facility. Two types exist. UKT is for tension only, and UKK is for compression only.
Feature
- Easy handling with less risk of malfunctions or glitches caused by external circumstances such as noise or static electricity due to the rugged mechanical construction
- Ideal for integration into facilities due to the compact design
- Selectable from 2 types to meet your measurement needs: UKT series (for tension) and UKK series (for compression)
- Shows real time value and peak value simultaneously with memory pointer
- Assists accurate measurement with tare ring to adjust zero
Specifications
| Model | UKT |
| Stroke | 10mm |
| Measuring units | See [Model lists] |
| Reading method | Real time/Peak hold (Memory pointer type) |
| Scales *1 | 100 lines |
| Accuracy | ±0.3%F. S or less |
| Operating environment | 0~+40℃ |
| Dimension | See [Dimension] |
| Weight *2 | Approx. 300g |
| Standard accessories | 4 pcs of tension attachments, Instruction manual, Carry case, Inspection certificate etc. |
* It is not suitable for breaking test with large impact or test with continues vibration due to its spring structures.
* 1 120 lines for 30N, 300N, 3K, 30K, 30lb.
* 2 The weight is depending on the range.
| Standard tension attachments for UKT | |||
| Small hook A-1(S-1) |
Flat tip A-2(S-2) |
Conical tip A-3(S-3) |
Chisel tip A-4(S-4) |
 |
 |
 |
 |
* Force gauges with capacities from 100N or less come with aluminum made attachments (A-type), 200N to 1000N come with steel made attachments (S-type).
| Standard compression attachments for UKK | |||
| Notched tip A-5(S-5) |
Extension shaft A-6(S-6) |
Large hook A-7(S-7) |
Y hook A-8(S-8) |
 |
 |
 |
 |
* Force gauges with capacities from 100N or less come with aluminum made attachments (A-type), 200N to 1000N come with steel made attachments (S-type).
| Model lists (N unit) | ||||
| Model | Capacity | Resolution | Thread | Standard attachments |
| UKT-100N | 100N | 1N | M6 | A-1, A-6 A-7, A-8 |
| แบรนด์สินค้า | IMADA |
|---|---|
| Order No. | UKT-100N |
