Relay Optical System Microscope Unit
VMU-T1
Microscope unit for configuring a varifocal optical system by incorporating the TAGLENS-T1, the objective lens and the camera.
| Tube lens magnification | 1X |
| Imaging FOV (diagonal) | ø11 mm |
| Applicable objective lenses | M Plan Apo Series |
| Options | Manual turret, Power turret, Polarizer and Analyzer, Focusing unit, X-Y stage, Simple stand |
Variable focal length range
| M Plan Apo Series | ||||||||
| Objective lens | 1X | 2X | 5X | 7.5X | 10X | 20X | 50X | |
| Depth of focus ×2 (mm)* | 0.88 | 0.18 | 0.028 | 0.012 | 0.007 | 0.003 | 0.0018 | |
| scan range (mm) | 16 | 4 | 0.64 | 0.28 | 0.16 | 0.04 | 0.007 | |
| Real FOV （mm） |
1/2" camera (V×H)** | 4.8 x 6.4 | 2.4 x 3.2 | 0.96 x 1.28 | 0.64 x 0.85 | 0.48 x 0.64 | 0.24 x 0.32 | 0.096 x 0.128 |
| 2/3" camera (V×H)** | 6.6 x 8.8 | 3.3 x 4.4 | 1.32 x 1.76 | 0.88 x 1.17 | 0.66 x 0.88 | 0.33 x 0.44 | 0.132 x 0.176 | |
Note: Not available for M Plan Apo HR 5X and 10X.
* Total in focus range without TAGLENS.
** V: Vertical field of view, H: Horizontal field of view
| แบรนด์สินค้า | MITUTOYO |
|---|---|
| Order No. | VMU-T1 |
