VUPO (Metric Threads) | Z-PRO Coated Spiral Pointed Taps | YAMAWA
ราคาต่ำสุด
THB 0.00
THB 0.00
พร้อมส่ง
SKU
YAM-VUPO Metric Threads
Product Features
- Durability is improved by premium powder HSS and special coating.
- Chip ejection efficiency is improved and cutting resistance is reduced by the unique cutting edge shape, achieving a good internal thread and long tool life.
- Proper tool projection length is secured, achieving a good supply of water soluble cutting fluid.
- This is most suitable for tapping with water soluble cutting fluid.
Tapping Data
Tapping Conditions [M10×1.5]
| Workpiece Material | SUS304 |
| Tapping Speed | 10m/min |
| Machinery Type | Machining center, vertical type |
| Tapping Fluid | Water soluble cutting fluid |
Tapping Data
Tapping Conditions [M10×1.5]
| Workpiece Material | SUS304 |
| Tapping Length | 20mm（2D） |
| Tapping Speed | 20m/min |
| Machinery Type | Machining center, vertical type |
| Tapping Fluid | Water soluble cutting fluid |
| VUPO | Competitor's tap | |
| After Tapping of 560 Holes |  |
 |
- Compatible with a wide range of work materials
This is compatible with a wide range of steel work materials, including general structural steel, carbon steel, and alloy steel.
Specification
Tapping Speeds depending on Materials
For long shank type, the recommended cutting speed is 30% less than the above.
Oversize
Segment：1F
|
Size |
Class |
Code |
Chamfer |
L (mm) |
ℓ (mm) |
ℓn (mm) |
ℓs (mm) |
Ds (mm) |
K (mm) |
ℓk (mm) |
No. of flutes |
TYPE |
|
For Metric Threads |
||||||||||||
|
M2×0.4 |
P2 |
1102101021 |
5P |
45 |
8 |
15 |
27 |
3 |
2.5 |
5 |
2 |
1 |
|
M2.2×0.45 |
P2 |
1102101024 |
5P |
45 |
9 |
15 |
27 |
3 |
2.5 |
5 |
2 |
1 |
|
M2.3×0.4 |
P2 |
1102101026 |
5P |
45 |
9 |
15 |
27 |
3 |
2.5 |
5 |
2 |
1 |
|
M2.5×0.45 |
P2 |
1102101029 |
5P |
50 |
8 |
15 |
32 |
3 |
2.5 |
5 |
2 |
1 |
|
M2.6×0.45 |
P2 |
1102101032 |
5P |
50 |
8 |
15 |
32 |
3 |
2.5 |
5 |
2 |
1 |
|
M3×0.5 |
P2 |
1102101035 |
5P |
56 |
9 |
18 |
32 |
4 |
3.2 |
6 |
3 |
1 |
|
M3×0.5 |
P3 |
1102201035 |
5P |
56 |
9 |
18 |
32 |
4 |
3.2 |
6 |
3 |
1 |
|
M3×0.5 |
P4 |
1102301035 |
5P |
56 |
9 |
18 |
32 |
4 |
3.2 |
6 |
3 |
1 |
|
M3×0.35 |
P2 |
1102101036 |
5P |
56 |
6.5 |
18 |
32 |
4 |
3.2 |
6 |
3 |
2 |
|
M3×0.35 |
P3 |
1102201036 |
5P |
56 |
6.5 |
18 |
32 |
4 |
3.2 |
6 |
3 |
2 |
|
M3×0.35 |
P4 |
1102301036 |
5P |
56 |
6.5 |
18 |
32 |
4 |
3.2 |
6 |
3 |
2 |
|
M4×0.7 |
P3 |
1102101042 |
5P |
63 |
13 |
21 |
36 |
5 |
4 |
7 |
3 |
1 |
|
M4×0.7 |
P4 |
1102201042 |
5P |
63 |
13 |
21 |
36 |
5 |
4 |
7 |
3 |
1 |
|
M4×0.7 |
P5 |
1102301042 |
5P |
63 |
13 |
21 |
36 |
5 |
4 |
7 |
3 |
1 |
|
M4×0.5 |
P2 |
1102101043 |
5P |
63 |
9 |
21 |
36 |
5 |
4 |
7 |
3 |
2 |
|
M4×0.5 |
P3 |
1102201043 |
5P |
63 |
9 |
21 |
36 |
5 |
4 |
7 |
3 |
2 |
|
M4×0.5 |
P4 |
1102301043 |
5P |
63 |
9 |
21 |
36 |
5 |
4 |
7 |
3 |
2 |
|
M5×0.8 |
P3 |
1102101049 |
5P |
70 |
14 |
25 |
40 |
5.5 |
4.5 |
7 |
3 |
1 |
|
M5×0.8 |
P4 |
1102201049 |
5P |
70 |
14 |
25 |
40 |
5.5 |
4.5 |
7 |
3 |
1 |
|
M5×0.8 |
P5 |
1102301049 |
5P |
70 |
14 |
25 |
40 |
5.5 |
4.5 |
7 |
3 |
1 |
|
M5×0.5 |
P2 |
1102101051 |
5P |
70 |
9 |
25 |
40 |
5.5 |
4.5 |
7 |
3 |
2 |
|
M5×0.5 |
P3 |
1102201051 |
5P |
70 |
9 |
25 |
40 |
5.5 |
4.5 |
7 |
3 |
2 |
|
M5×0.5 |
P4 |
1102301051 |
5P |
70 |
9 |
25 |
40 |
5.5 |
4.5 |
7 |
3 |
2 |
|
M6×1 |
P3 |
1102101055 |
5P |
80 |
15 |
30 |
45 |
6 |
4.5 |
7 |
3 |
1 |
|
M6×1 |
P4 |
1102201055 |
5P |
80 |
15 |
30 |
45 |
6 |
4.5 |
7 |
3 |
1 |
|
M6×1 |
P5 |
1102301055 |
5P |
80 |
15 |
30 |
45 |
6 |
4.5 |
7 |
3 |
1 |
|
M6×0.75 |
P2 |
1102101056 |
5P |
80 |
15 |
30 |
45 |
6 |
4.5 |
7 |
3 |
1 |
|
M6×0.75 |
P3 |
1102201056 |
5P |
80 |
15 |
30 |
45 |
6 |
4.5 |
7 |
3 |
1 |
|
M6×0.75 |
P4 |
1102301056 |
5P |
80 |
15 |
30 |
45 |
6 |
4.5 |
7 |
3 |
1 |
|
M6×0.5 |
P2 |
1102101057 |
5P |
80 |
9 |
30 |
45 |
6 |
4.5 |
7 |
3 |
2 |
|
M6×0.5 |
P3 |
1102201057 |
5P |
80 |
9 |
30 |
45 |
6 |
4.5 |
7 |
3 |
2 |
|
M6×0.5 |
P4 |
1102301057 |
5P |
80 |
9 |
30 |
45 |
6 |
4.5 |
7 |
3 |
2 |
|
M8×1.25 |
P3 |
1102101064 |
5P |
90 |
19 |
- |
46 |
6.2 |
5 |
8 |
3 |
3 |
|
M8×1.25 |
P4 |
1102201064 |
5P |
90 |
19 |
- |
46 |
6.2 |
5 |
8 |
3 |
3 |
|
M8×1.25 |
P5 |
1102301064 |
5P |
90 |
19 |
- |
46 |
6.2 |
5 |
8 |
3 |
3 |
|
M8×1 |
P3 |
1102101065 |
5P |
90 |
19 |
- |
46 |
6.2 |
5 |
8 |
3 |
3 |
|
M8×1 |
P4 |
1102201065 |
5P |
90 |
19 |
- |
46 |
6.2 |
5 |
8 |
3 |
3 |
|
M8×1 |
P5 |
1102301065 |
5P |
90 |
19 |
- |
46 |
6.2 |
5 |
8 |
3 |
3 |
|
M10×1.5 |
P3 |
1102101078 |
5P |
100 |
23 |
- |
51 |
7 |
5.5 |
8 |
3 |
3 |
|
M10×1.5 |
P4 |
1102201078 |
5P |
100 |
23 |
- |
51 |
7 |
5.5 |
8 |
3 |
3 |
|
M10×1.5 |
P5 |
1102301078 |
5P |
100 |
23 |
- |
51 |
7 |
5.5 |
8 |
3 |
3 |
|
M10×1.25 |
P3 |
1102101079 |
5P |
100 |
23 |
- |
51 |
7 |
5.5 |
8 |
3 |
3 |
|
M10×1.25 |
P4 |
1102201079 |
5P |
100 |
23 |
- |
51 |
7 |
5.5 |
8 |
3 |
3 |
|
M10×1.25 |
P5 |
1102301079 |
5P |
100 |
23 |
- |
51 |
7 |
5.5 |
8 |
3 |
3 |
|
M10×1 |
P3 |
1102101080 |
5P |
100 |
23 |
- |
51 |
7 |
5.5 |
8 |
3 |
3 |
|
M10×1 |
P4 |
1102201080 |
5P |
100 |
23 |
- |
51 |
7 |
5.5 |
8 |
3 |
3 |
|
M10×1 |
P5 |
1102301080 |
5P |
100 |
23 |
- |
51 |
7 |
5.5 |
8 |
3 |
3 |
|
M12×1.75 |
P4 |
1102101088 |
5P |
110 |
26 |
- |
56 |
8.5 |
6.5 |
9 |
3 |
3 |
|
M12×1.75 |
P5 |
1102201088 |
5P |
110 |
26 |
- |
56 |
8.5 |
6.5 |
9 |
3 |
3 |
|
M12×1.75 |
P6 |
1102301088 |
5P |
110 |
26 |
- |
56 |
8.5 |
6.5 |
9 |
3 |
3 |
|
M12×1.5 |
P3 |
1102101089 |
5P |
110 |
26 |
- |
56 |
8.5 |
6.5 |
9 |
3 |
3 |
|
M12×1.5 |
P4 |
1102201089 |
5P |
110 |
26 |
- |
56 |
8.5 |
6.5 |
9 |
3 |
3 |
|
M12×1.5 |
P5 |
1102301089 |
5P |
110 |
26 |
- |
56 |
8.5 |
6.5 |
9 |
3 |
3 |
|
M12×1.25 |
P4 |
1102101090 |
5P |
110 |
26 |
- |
56 |
8.5 |
6.5 |
9 |
3 |
3 |
|
M12×1.25 |
P5 |
1102201090 |
5P |
110 |
26 |
- |
56 |
8.5 |
6.5 |
9 |
3 |
3 |
|
M12×1.25 |
P6 |
1102301090 |
5P |
110 |
26 |
- |
56 |
8.5 |
6.5 |
9 |
3 |
3 |
|
M14×2 |
P4 |
1102101100 |
5P |
110 |
26 |
- |
56 |
10.5 |
8 |
11 |
3 |
3 |
|
M14×2 |
P5 |
1102201100 |
5P |
110 |
26 |
- |
56 |
10.5 |
8 |
11 |
3 |
3 |
|
M14×2 |
P6 |
1102301100 |
5P |
110 |
26 |
- |
56 |
10.5 |
8 |
11 |
3 |
3 |
|
M14×1.5 |
P3 |
1102101102 |
5P |
110 |
26 |
- |
56 |
10.5 |
8 |
11 |
3 |
3 |
|
M14×1.5 |
P4 |
1102201102 |
5P |
110 |
26 |
- |
56 |
10.5 |
8 |
11 |
3 |
3 |
|
M14×1.5 |
P5 |
1102301102 |
5P |
110 |
26 |
- |
56 |
10.5 |
8 |
11 |
3 |
3 |
|
M16×2 |
P4 |
1102101114 |
5P |
110 |
26 |
- |
56 |
12.5 |
10 |
13 |
3 |
3 |
|
M16×2 |
P5 |
1102201114 |
5P |
110 |
26 |
- |
56 |
12.5 |
10 |
13 |
3 |
3 |
|
M16×2 |
P6 |
1102301114 |
5P |
110 |
26 |
- |
56 |
12.5 |
10 |
13 |
3 |
3 |
|
M16×1.5 |
P3 |
1102101116 |
5P |
110 |
26 |
- |
56 |
12.5 |
10 |
13 |
3 |
3 |
|
M16×1.5 |
P4 |
1102201116 |
5P |
110 |
26 |
- |
56 |
12.5 |
10 |
13 |
3 |
3 |
|
M16×1.5 |
P5 |
1102301116 |
5P |
110 |
26 |
- |
56 |
12.5 |
10 |
13 |
3 |
3 |
|
M18×2.5 |
P5 |
1102101128 |
5P |
125 |
33 |
- |
64 |
14 |
11 |
14 |
3 |
3 |
|
M18×1.5 |
P4 |
1102101130 |
5P |
125 |
33 |
- |
64 |
14 |
11 |
14 |
3 |
3 |
|
M20×2.5 |
P5 |
1102101141 |
5P |
140 |
33 |
- |
71 |
15 |
12 |
15 |
3 |
4 |
|
M20×1.5 |
P4 |
1102101144 |
5P |
140 |
33 |
- |
71 |
15 |
12 |
15 |
3 |
4 |
|
M22×2.5 |
P5 |
1102101156 |
5P |
140 |
33 |
- |
71 |
17 |
13 |
16 |
3 |
4 |
|
M22×1.5 |
P4 |
1102101158 |
5P |
140 |
33 |
- |
71 |
17 |
13 |
16 |
3 |
4 |
|
M24×3 |
P5 |
1102101167 |
5P |
160 |
37 |
- |
82 |
19 |
15 |
18 |
3 |
4 |
|
M24×1.5 |
P4 |
1102101170 |
5P |
160 |
37 |
- |
82 |
19 |
15 |
18 |
3 |
4 |
