VUSP22X2.5 (1101101156) | Z-PRO Coated Spiral Fluted Taps Specification | YAMAWA
THB 0.00
*ราคายังไม่รวม VAT
พร้อมส่ง
SKU
1101101156
QTY:
4
- Durability is improved by premium powder HSS and special coating.
- Chip ejection efficiency is improved and cutting resistance is reduced by the unique cutting edge shape, achieving a good internal thread and long tool life.
- Proper tool projection length is secured, preventing chips from interfering with the holder.
- This is most suitable for tapping with water soluble cutting fluid.
| File PDF |
| แบรนด์สินค้า | YAMAWA |
|---|---|
| Order No. | VUSP22X2.5 (1101101156) |
| Model | VUSP |
| Size | M22X2.5 |
| Class | P5 |
| Chamfer | 2.5P |
| Overall length (L) | 140 |
| Thread length (ℓ) | 20 |
| Thread + Neck length (ℓn) | - |
| Shank length (ℓs) | 71 |
| Shank dia. (Ds) | 17 |
| Size of Square (K) | 13 |
| Length of square (ℓk) | 16 |
