VUSP | Z-PRO Coated Spiral Fluted Taps Specification | YAMAWA

YAMAWA
เป็นคนแรกที่รีวิวสินค้านี้
ราคาต่ำสุด THB 0.00 THB 0.00
พร้อมส่ง
SKU
YAM-VUSP
เพิ่มไปยังรายการโปรด เพิ่มไปเปรียบเทียบ
  • Durability is improved by premium powder HSS and special coating.
  • Chip ejection efficiency is improved and cutting resistance is reduced by the unique cutting edge shape, achieving a good internal thread and long tool life.
  • Proper tool projection length is secured, preventing chips from interfering with the holder.
  • This is most suitable for tapping with water soluble cutting fluid.
File PDF
VUSP | Z-PRO Coated Spiral Fluted Taps Specification | YAMAWA
VUSP | Z-PRO Coated Spiral Fluted Taps Specification | YAMAWA
Specification
Tapping Speeds depending on Materials
＊For long shank type, the recommended cutting speed is 30% less than theabove.

          Oversize
Segment：1C
Size Class Code Chamfer L
(mm)		 ℓ
(mm)		 ℓn
(mm)		 ℓs
(mm)		 Ds
(mm)		 K
(mm)		 ℓk
(mm)		 No. of
flutes		 TYPE
For Metric Threads
M3×0.5 P2 1101101035 2.5P 56 5 18 32 4 3.2 6 3 1
M3×0.5 P3 1101201035 2.5P 56 5 18 32 4 3.2 6 3 1
M3×0.5 P4 1101301035 2.5P 56 5 18 32 4 3.2 6 3 1
M3×0.35 P2 1101101036 2.5P 56 5 18 32 4 3.2 6 3 1
M3×0.35 P3 1101201036 2.5P 56 5 18 32 4 3.2 6 3 1
M3×0.35 P4 1101301036 2.5P 56 5 18 32 4 3.2 6 3 1
M4×0.7 P2 1101101042 2.5P 63 7 21 36 5 4 7 3 1
M4×0.7 P3 1101201042 2.5P 63 7 21 36 5 4 7 3 1
M4×0.7 P4 1101301042 2.5P 63 7 21 36 5 4 7 3 1
M4×0.5 P2 1101101043 2.5P 63 5 21 36 5 4 7 3 1
M4×0.5 P3 1101201043 2.5P 63 5 21 36 5 4 7 3 1
M4×0.5 P4 1101301043 2.5P 63 5 21 36 5 4 7 3 1
M5×0.8 P2 1101101049 2.5P 70 9 25 40 5.5 4.5 7 3 1
M5×0.8 P3 1101201049 2.5P 70 9 25 40 5.5 4.5 7 3 1
M5×0.8 P4 1101301049 2.5P 70 9 25 40 5.5 4.5 7 3 1
M5×0.5 P2 1101101051 2.5P 70 6 25 40 5.5 4.5 7 3 1
M5×0.5 P3 1101201051 2.5P 70 6 25 40 5.5 4.5 7 3 1
M5×0.5 P4 1101301051 2.5P 70 6 25 40 5.5 4.5 7 3 1
M6×1 P2 1101101055 2.5P 80 11 30 45 6 4.5 7 3 1
M6×1 P3 1101201055 2.5P 80 11 30 45 6 4.5 7 3 1
M6×1 P4 1101301055 2.5P 80 11 30 45 6 4.5 7 3 1
M6×0.75 P2 1101101056 2.5P 80 8 30 45 6 4.5 7 3 1
M6×0.75 P3 1101201056 2.5P 80 8 30 45 6 4.5 7 3 1
M6×0.75 P4 1101301056 2.5P 80 8 30 45 6 4.5 7 3 1
M6×0.5 P2 1101101057 2.5P 80 8 30 45 6 4.5 7 3 1
M6×0.5 P3 1101201057 2.5P 80 8 30 45 6 4.5 7 3 1
M6×0.5 P4 1101301057 2.5P 80 8 30 45 6 4.5 7 3 1
M8×1.25 P3 1101101064 2.5P 90 12 - 46 6.2 5 8 3 2
M8×1.25 P4 1101201064 2.5P 90 12 - 46 6.2 5 8 3 2
M8×1.25 P5 1101301064 2.5P 90 12 - 46 6.2 5 8 3 2
M8×1 P3 1101101065 2.5P 90 12 - 46 6.2 5 8 3 2
M8×1 P4 1101201065 2.5P 90 12 - 46 6.2 5 8 3 2
M8×1 P5 1101301065 2.5P 90 12 - 46 6.2 5 8 3 2
M10×1.5 P3 1101101078 2.5P 100 13 - 51 7 5.5 8 3 2
M10×1.5 P4 1101201078 2.5P 100 13 - 51 7 5.5 8 3 2
M10×1.5 P5 1101301078 2.5P 100 13 - 51 7 5.5 8 3 2
M10×1.25 P3 1101101079 2.5P 100 13 - 51 7 5.5 8 3 2
M10×1.25 P4 1101201079 2.5P 100 13 - 51 7 5.5 8 3 2
M10×1.25 P5 1101301079 2.5P 100 13 - 51 7 5.5 8 3 2
M10×1 P3 1101101080 2.5P 100 13 - 51 7 5.5 8 3 2
M10×1 P4 1101201080 2.5P 100 13 - 51 7 5.5 8 3 2
M10×1 P5 1101301080 2.5P 100 13 - 51 7 5.5 8 3 2
M12×1.75 P4 1101101088 2.5P 110 15 - 56 8.5 6.5 9 3 2
M12×1.75 P5 1101201088 2.5P 110 15 - 56 8.5 6.5 9 3 2
M12×1.75 P6 1101301088 2.5P 110 15 - 56 8.5 6.5 9 3 2
M12×1.5 P3 1101101089 2.5P 110 15 - 56 8.5 6.5 9 3 2
M12×1.5 P4 1101201089 2.5P 110 15 - 56 8.5 6.5 9 3 2
M12×1.5 P5 1101301089 2.5P 110 15 - 56 8.5 6.5 9 3 2
M12×1.25 P3 1101101090 2.5P 110 15 - 56 8.5 6.5 9 3 2
M12×1.25 P4 1101201090 2.5P 110 15 - 56 8.5 6.5 9 3 2
M12×1.25 P5 1101301090 2.5P 110 15 - 56 8.5 6.5 9 3 2
M14×2 P4 1101101100 2.5P 110 18 - 56 10.5 8 11 3 2
M14×2 P5 1101201100 2.5P 110 18 - 56 10.5 8 11 3 2
M14×2 P6 1101301100 2.5P 110 18 - 56 10.5 8 11 3 2
M14×1.5 P3 1101101102 2.5P 110 14 - 56 10.5 8 11 3 2
M14×1.5 P4 1101201102 2.5P 110 14 - 56 10.5 8 11 3 2
M14×1.5 P5 1101301102 2.5P 110 14 - 56 10.5 8 11 3 2
M16×2 P4 1101101114 2.5P 110 18 - 56 12.5 10 13 3 2
M16×2 P5 1101201114 2.5P 110 18 - 56 12.5 10 13 3 2
M16×2 P6 1101301114 2.5P 110 18 - 56 12.5 10 13 3 2
M16×1.5 P3 1101101116 2.5P 110 14 - 56 12.5 10 13 3 2
M16×1.5 P4 1101201116 2.5P 110 14 - 56 12.5 10 13 3 2
M16×1.5 P5 1101301116 2.5P 110 14 - 56 12.5 10 13 3 2
M18×2.5 P5 1101101128 2.5P 125 20 - 64 14 11 14 4 2
M18×1.5 P4 1101101130 2.5P 125 14 - 64 14 11 14 3 2
M20×2.5 P5 1101101141 2.5P 140 20 - 71 15 12 15 4 3
M20×1.5 P4 1101101144 2.5P 140 14 - 71 15 12 15 3 3
M22×2.5 P5 1101101156 2.5P 140 20 - 71 17 13 16 3 3
M22×1.5 P4 1101101158 2.5P 140 14 - 71 17 13 16 3 3
M24×3 P5 1101101167 2.5P 160 25 - 82 19 15 18 4 3
M24×1.5 P4 1101101170 2.5P 160 18 - 82 19 15 18 3 3
Long Shank, for Metric Threads
M3×0.5 P2 2101101035 2.5P 100 5 18 32 4 3.2 6 3 4
M3×0.35 P2 2101101036 2.5P 100 5 18 32 4 3.2 6 3 4
M4×0.7 P2 2101101042 2.5P 100 7 21 36 5 4 7 3 4
M4×0.5 P2 2101101043 2.5P 100 5 21 36 5 4 7 3 4
M5×0.8 P2 2101101049 2.5P 100 9 25 40 5.5 4.5 7 3 4
M5×0.5 P2 2101101051 2.5P 100 6 25 40 5.5 4.5 7 3 4
M6×1 P2 2101101055 2.5P 100 11 30 45 6 4.5 7 3 4
M6×0.75 P2 2101101056 2.5P 100 8 30 45 6 4.5 7 3 4
M6×0.5 P2 2101101057 2.5P 100 8 30 45 6 4.5 7 3 4
M8×1.25 P3 2101101064 2.5P 150 12 - 46 6.2 5 8 3 5
M8×1 P3 2101101065 2.5P 150 12 - 46 6.2 5 8 3 5
M10×1.5 P3 2101101078 2.5P 150 13 - 51 7 5.5 8 3 5
M10×1.25 P3 2101101079 2.5P 150 13 - 51 7 5.5 8 3 5
M10×1 P3 2101101080 2.5P 150 13 - 51 7 5.5 8 3 5
M12×1.75 P4 2101101088 2.5P 150 15 - 56 8.5 6.5 9 3 5
M12×1.5 P3 2101101089 2.5P 150 15 - 56 8.5 6.5 9 3 5
M12×1.25 P3 2101101090 2.5P 150 15 - 56 8.5 6.5 9 3 5
M14×2 P4 2101101100 2.5P 150 18 - 56 10.5 8 11 3 5
M14×1.5 P3 2101101102 2.5P 150 14 - 56 10.5 8 11 3 5
M16×2 P4 2101101114 2.5P 150 18 - 56 12.5 10 13 3 5
M16×1.5 P3 2101101116 2.5P 150 14 - 56 12.5 10 13 3 5
