RADIUS GAUGES 272 TYPE | FUJI TOOL
ราคาต่ำสุด
THB 0.00
พร้อมส่ง
SKU
FUJ-272
Features
Used for checking internal and external radius on each leaf or convex and concave surfaces. Toolmakers and Inspectors can measure the radii of the edges and corners of works. Each leaves stamped with size. High precision is guaranteed.
Material : SPCC Steel
272-112 • 272-213 : Stainless Steel
Accuracy : 0.1R~3.0R(±0.03mm)
3.25R~23.0R(±0.04mm)
24.0R~30.0R (±0.05mm)
31.0R~50.0R(±0.08mm)
mm
| Order No. | Model No. | Leaves | Size Composition / Contrnts |
| 01-408 | 272MAA | 10 | 0.1, 0.2, 0.3, 0.4, 0.5, 0.6, 0.7, 0.8, 0.9, 1.0 |
| 01-415 | 272-112 | 10 | 1.1, 1.2, 1.3, 1.4, 1.5, 1.6, 1.7, 1.8, 1.9, 2.0 |
| 01-416 | 272-213 | 10 | 2.1, 2.2, 2.3, 2.4, 2.5, 2.6, 2.7, 2.8, 2.9, 3.0 |
| 01-409 | 272MA | 18 | 0.75, 1.0, 1.25, 1.5, 1.75, 2.0, 2.25, 2.5, 2.75, 3.0, 3.25, 3.5, 3.75, 4.0, 4.25, 4.5, 4.75, 5.0 |
| 01-410 | 272MB | 16 | 5.5, 6.0, 6.5, 7.0, 7.5, 8.0, 8.5, 9.0, 9.5, 10.0, 10.5, 11.0, 11.5, 12.0, 12.5, 13.0 |
| 01-411 | 272MC | 10 | 13.0, 14.0, 15.0, 16.0, 17.0, 18.0, 19.0, 20.0 ,21.0, 22.0 |
| 01-412 | 272MD | 8 | 23.0, 24.0, 25.0, 26.0, 27.0, 28.0, 29.0, 30.0 |
| 01-413 | 272ME | 10 | 31.0, 32.0, 33.0, 34.0, 35.0, 36.0, 37.0, 38.0, 39.0, 40.0 |
| 01-414 | 272MF | 10 | 41.0, 42.0, 43.0, 44.0, 45.0, 46.0, 47.0, 48.0, 49.0, 50.0 |
inch
| Order No. | Model No. | Leaves | Size Composition / Contrnts |
| 01-401 | 272A | 16 | 1/32” to 17/64” by 64ths |
| 01-402 | 272B | 16 | 9/32” to 1/2” by 64ths |
| แบรนด์สินค้า | FUJI TOOL |
|---|
