1. Proven ABS (absolute) sensor

Mitutoyo’s unique ABS (Absolute) sensor restores the last origin position automatically when the indicator is turned on. This allows quick-start operation, which is especially useful in multipoint measurement. Also, INC (Incremental) measurements can be made from any arbitrary position at the touch of a button, with restoration to ABS measurement mode being just as easy.

2. Rated to IP66 water- and dust proofing standard and oil resistance improved

This indicator can be used satisfactorily even in adverse environments where it is subject
to splashing by cutting fluid and coolant. Oil-resistant materials are used for external parts such as switches.

3. Slim body design is advantageous for multi point measurements

Slim design extends the application range to multipoint measurement and allows fixture downsizing.

4. Improvement

SIMPLE PROCUREMENT

With the Toolbase dispensing system customi zed to your needs, cost-intensive processes such as ongoing inventory control, demand determination and ordering via purchasing are a thing of the past.

EFFICIENT PROCESSES

An automated system reduces your process costs in procurement, while the reliability of the supply for your tools and other consumables increases.

SYSTEM SUPPLY

Now, everything is automated, with complete transparency at the same time. Current inven tory and consumption data are also available in the shop-floor systems. Process designs, simulations: Everything is simple. At the same time, cost control increases while process costs decrease.

AMORTISATION / AMORTIZATION:

6 - 18

MONATE / MONTHS

FEATURES

Calculation function operates on spindle displacement.

Entering the appropriate formula factors for a fixture dedicated to the application enables direct measurement readout, thereby eliminating any need for the conversion tables. previously needed for those applications where fixtures are typically used.

Peak-Value TIR/MAX/MIN Hold enables GO/±NG judgement for peak value.

Simple operation of many functions with five buttons and status icons.

Wide LCD and new analog bar graph are now standard on all models.

It performs sampling in fifty times per second and it enables to detect peak value more correctly.

FEATURES

Peak-Value TIR/MAX/MIN Hold enables GO/±NG judgement for peak value.

Simple operation of many functions with five buttons and status icons

Wide LCD and new analog

Cam rotation mechanism

Our proprietary Tang-Thru nut incorporates cam rotation mechanism, which turns the driving tip counter-clockwise by 12 degrees when the handle is hit with a hammer. IMPACTA leverages impact acceleration to remove stuck screws.

Non-slip

Non-slip surface secures a firm grip even when your hands are covered with oil.

When used with oil-covered hands, tightening torque becomes 26% higher with “MEGADORA  IMPACTA”  than with other normal screwdrivers. Non-slip surface makes the difference.

HAIMER: WORLDWIDE DISTRIBUTION PARTNER

The Haimer Group is now a global competence partner and offers its worldwide customers WinTool and Toolbase products as a full-service provider.

WINTOOL – THE LEADING PROVIDER FOR  TOOL & DATA MANAGEMENT

With WinTool you simplify your manufacturing processes, reduce production costs and increase productivity. You benefit from shorter programming and setup times, reduce the stock as well as the tool variety and work with organized and integrated manufacturing documentation.

Machining Data Management with WinTool

Are you familiar with the term “Machining Data Management”? WinTool is CNC file and tool management, Industry 4.0 and Lean Management in one package. WinTool is the process-oriented tool management,  so that you use your machines, manpower and  resources efficiently in order to become a leading industrial machining company!

Resolution switchable to 0.01 or 0.005 mm

Simple switching operation

Output function for all models

Connectable to the Digimatic Mini-processor DP-1VR, or to a PC via the input tool

Highly efficient operation plus preset-function convenience

Preset functions enable two reference planes to be set relative to surface plate datum

• Example of preset 1
To measure a height of 70 mm, with a reference plane height of 50 mm
• Example of preset 2
 To measure a height of 130 mm, with a reference plane height of 150 mm

Large LCD characters

Character height of 11 mm makes display easy to read and avoids eyestrain.

Slider handle

Inclined handle improves slider ergonomics.

HD-30AX display

• Design registration pending• Large function buttons. Frequently used buttons are positioned on the right-hand side of the panel for easy operation.
• Uses the proven alarm system as used on
