หน้า 5 - PRODUCT HIGHLIGHT
-
June 30, 2025
IX-EPDB-TH3
Ball End Mill for Hardened Steel
“IX” changes the concept of carbide!
Features of IX-EPDB-TH3
- Uses a newly-developed ultra-fine-graincarbide alloy to combine high wear resistance and chipping resistance.
- Uses a TH3 coating designed for machining hardened steel, offering outstanding wear resistance and heat resistance.
- Greatly improves tool life, especially when machining 60HRC class hardened steel.
Features 01 Next-generation carbide alloy for machining hardened stee ●Features refined material structure with approximately 10% greater hardness than conventional materials
●Incorporates next-generation additive elements to combine high wear resistance (hardness) and chipping
resistance (toughness)Features 02 Newly designed cutting edge profile with superior durability Effectively reduces chipping common when machining hardened steel.
Features 03 Outer diameter measurement marking & short shank design -
June 19, 2025
QM-Height Series - High-Performance Height Gage
This is a High-accuracy digital height gauge and multifunction measurement.
Features
- Best-in-class accuracy ±(2.4+2.1L/600) μm
- Built-in pneumatic flotation system enables smooth movement over a surface plate. Models without the air suspension feature are also available.
- Simple-to-use control panel enables most measurements to be made with a single keystroke.
- Battery life of 1200 hours in continuous use with four AA batteries, an improvement from 300 hours.
- Install the optional U-WAVE-T measurement data communication system to output measurement data directly to Excel or SPC software on your PC.
GO/±NG judgment by LED and display symbols
LEDs indicate tolerance judgment status – green for GO, red for +NG, and orange for -NG. Status is also indicated by corresponding symbols appearing on the display.
Intuitive buttons and layout
The symbols are for frequently used keys.
Cross-keys provide better operability.
Inside/outside
-
June 19, 2025
High-Accuracy Height Gage Linear Height LH-600F/FG
high-precision 2D linear height gauge for complex work provides high precision up to ± (1.1+0.6L/600) μm
Easy operation using keypad and touch screen navigation, even suitable for beginners
Conduct various measurements such as 2D measurement and perpendicularity measurement with just one tool
Versatile measurements through optional probes
Enhanced data output functions make it easier to manage your measurement data
Easy operation using keypad and touch screen navigation
Contextual guidance on the large-screen touch panel supports your measurements
Simple, straightforward keys with icons
Icons allow the user to find the required operation at a glance.Touch panel with guidance
Measurement guidance is displayed on the large touch panel of the 8.4-inch color LCD, enabling intuitive operation.Fantastic features for shop-floor use
Automatic scale check
On start up, the user is led through the menu to set the scale origin and run -
June 19, 2025
ABS Digimatic Height Gage Series 570
The New Standard in Smart and Reliable Height Measurement
Feature
Maximum permissible error EMPE : ±0.03 mm, ±0.05 mm, ±0.0015 in/±0.03 mm,±0.0020 in/±0.05 mm
Measuring range : 0 to 300 mm,0 to 600 mm,0 to 12 in/0 to 300 mm, 0 to 18 in/0 to 450 mm, 0 to 24 in/0 to 600 mm
Resolution : 0.01 mm,0.0005 in/0.01 mm
Functions : ON/OFF, ORIGIN, ZERO/ABS, HOLD/DATA, inch/mm conversion*
Drive method : Slider-feed wheel (manual)
Data output : DIGIMATIC d1
Max. response speed : Unlimited
LCD character height : 12 mm
Helps transform manufacturing sites into smart factories
The design of the case allows for easy installation of U-WAVE (optional), which enables wireless transmission of measurement data, promoting smarter use of data in manufacturing sites.
Supports smooth and reliable measurement operations
The handle for moving the slider enables smooth vertical movement. In addition, the highly rigid pillars and large clamp levers
-
May 19, 2025
Evolutionary Advancement
Highly Advanced Non-contact Measurement Technologies
Well-designed main unit structured for high-accuracy measurement and autofocus. Integration of these high-performance technologies has made 3D non-contact measurement a reality.
The QUICK VISION Pro, our CNC vision measuring machine family, never stops evolving
Enables High-Throughput Measurements Required for Vision Measuring Systems
In recent years, the technology surrounding our lives has entered a period of substantial change. Daily updates and technological innovations in motorized vehicles, 5G communications, and IoT technologies are evolving with unprecedented speed.
The QUICK VISION Pro was developed to keep pace with these technological innovations and industrial challenges. Experience the high-throughput non-contact measurement that Mitutoyo offers.
MEDICAL
-Three unique industries benefiting from Mitutoyo’s high reliability. «Medical»
Ultra-small
Medical devices requiring high accuracy -
May 16, 2025
Universal 3D-Taste
Der Universal 3D-Taster ist ein sehr präzises und vielseitiges Messgerät für Fräs- und Erodiermaschinen (isolierter Tasteinsatz). Er wird in die Frässpindel bzw. in den Senkkopf eingespannt und ermöglicht es, die Spindelachse exakt an Werkstück- oder Vorrichtungskanten zu positionieren. Somit können schnell und einfach Werkstück-Nullpunkte gesetzt und Längenmessungen durchgeführt werden. Die Antast richtung ist beliebig (X-, Y-, Z-Achse). Die Messuhr schlägt immer in die gleiche Richtung aus und zeigt den Abstand zwischen Spindelachse und Werkstück an. Sobald die Anzeige auf Null steht, befindet sich die Spindelachse genau an der Werkstückkante. Auf Anhieb, ohne langes Probieren, ohne zu Rechnen, ohne Vorzeichenprobleme. Das reduziert die Nebenkosten, steigert die Produktivität und entlastet die Mitarbeiter.
Es sind kurze wie auch lange Tasteinsätze verfügbar, die ohne Werkzeug gewechselt werden können. Nach Wechsel eines Tasteinsatzes ist keine Neukalibrierung
-
April 30, 2025
MERLIC – Your Easy-to-Use
Machine Vision SoftwareMERLIC is an all-in-one software product for quickly building machine vision applications without programming. It is based on MVTec's extensive machine vision expertise and combines reliable, fast performance with ease of use. Intuitive interaction concepts like easyTouch provide an efficient workflow, which leads to time and cost savings. MERLIC's flexible licensing model allows you to choose the package – and price – that exactly fits the scope of your application.
IMAGE PROCESSING TOOLS IN MERLIC
∎ 3D vision with height images ∎ Deep learning (AI)*
∎ Alignment ∎ Defect detection
∎ Checking ∎ Measuring
∎ Code reading ∎ Reading (OCR)
∎ Counting ∎ Extendable with MVTec HALCON*With the free MVTec Deep
-
April 30, 2025
3D Vision & AI for Robots and More
MECH-MIND ROBOTICS
AI + 3D Industrial Automation Solution
Mech-Mind is an industry-leading provider of 3D vision products and all-in-one robot solutions for industrial automation. With the comprehensive product portfolio, Mech-Mind empowers partners and system integrators to manage the most demanding robotic applications and brings automation to the next level.
Mech-Eye
Industrial 3D Sensors• Mech-Eye Industrial 3D Cameras: high accuracy, fast scanning, and resistance to ambient light
• Mech-Eye 3D Laser Profilers: 4K resolution, fast scan rate, and micron-level precision
• IP65/IP67 protection and CE, FCC, VCCI, UKCA, KC, ISED, NRTL, and RoHS certified
• Multiple model optionsMech-Vision
Machine Vision Software• Code-free graphical user interface
• Extensive solution library
• Easy integration
• Various vision tools integrated
• Integrated 600+ robotsMech-DLK
Deep Learning Software• Intuitive graphical user interface
• Visualized model validation -
April 29, 2025
ROUNDTRACER Flash- MITUTOYO Measurement and Analysis made easy | JSR GROUP
APPLICATION EXAMPLE
9x Dynamic Diameters
2x Arc Radii
4x Axial Distances
3x Groove Diameters
1x Cylindricity
1x Chamfer Angle
MEASURING CYCLE TIME: 5.6 seconds!Roundtracer Flash is an optical measuring unit based on side-by-side 2D image architecture.
This means that images that are acquired by different sensors are perfectly combined together in order to generate one single resultant image of the part with zero discontinuities and no gaps at the stitching edges.
As a result, Roundtracer Flash is capable of measuring parts up to 300 mm in length without any vertical movement of the sensors or the part itself.FAST
With the absence of Z-axis motion the optical acquisition of the complete part - which consumes time on other systems - is
performed almost instantaneously on the Roundtracer Flash.
Therefore its cycle time is impressively fast. For example, it executes 100 static measurements in just 2 seconds -
April 28, 2025
♦ หน้าจอแสดงแบบสัมผัส 4.3 นิ้ว
♦ รูปทรงสมาร์ท และกระทัดรัด
♦ รองรับหลายภาษา
♦ รวดเร็ว ใช้งานง่ายเมื่อตั้งค่ากับมาสเตอร์
♦ SMP รับรองมาตรฐาน (Flow Type for Jet) และสามารถเชื่อมต่ออุปกรณ์ได้ทุกยี่ห้อ
♦ ฟังก์ชั่นเพิ่มเติม เช่น OK, NG การใช้งานเริ่มต้นวัดแบบไดรามิก เป็นไปได้โดยการใช้ M-Bus เป็นตัวเลือก โปรดดูรายละเอียดเพิ่มเติมที่ตัวอย่างการเชื่อมต่ออุปกรณ์
♦ ส่งออกข้อมูลผ่าน USB โดยตรงไปที่ Excel หรือการใช้งาน USB Memory Stick ได้ง่าย
♦ รองรับการคำนวนค่าเฉลี่ย
♦ สามารถจัดกลุ่มตั้งค่าข้อมูลได้สูงสุด 16 กลุ่ม
♦ หน้าจอแสดงผลตัวเลือกหลากหลายรูปแบบ
♦ หน้าจอแสดงผล OK NG แบบ 3 สี สังเกตุง่ายชัดเจน
ตัวอย่างการเชื่อมต่ออุปกรณ์
• หน่วยความจำ USB Memory stick หรือ Computer สามารถเชื่อมต่อโดยตรงกับเครื่องได้โดยตรง
• การส่งผลข้อมูลตรวจค่าวัด จะแสดงผลบนหน้าจอ
• การวัดค่า OK, NG โดยการใช้งานจะจัดอันดับตามผลค่าการวัด และ M-Bus Module คือตัวเลือก สามารถใช้สัญญาณ Input ได้ทั้งหมด (14 In-Output)
• สามารถใช้ตรวจสอบอุปกรณ์ "Robot" โดยอัตโนมัติ และการตั้งค่าการสื่อสารให้เป็นไปได้
• ส่งข้อมูลด้วยสัญญาณ
