Monthly Archives: June 2025
-
June 19, 2025
QM-Height Series - High-Performance Height Gage
This is a High-accuracy digital height gauge and multifunction measurement.
Features
- Best-in-class accuracy ±(2.4+2.1L/600) μm
- Built-in pneumatic flotation system enables smooth movement over a surface plate. Models without the air suspension feature are also available.
- Simple-to-use control panel enables most measurements to be made with a single keystroke.
- Battery life of 1200 hours in continuous use with four AA batteries, an improvement from 300 hours.
- Install the optional U-WAVE-T measurement data communication system to output measurement data directly to Excel or SPC software on your PC.
GO/±NG judgment by LED and display symbols
LEDs indicate tolerance judgment status – green for GO, red for +NG, and orange for -NG. Status is also indicated by corresponding symbols appearing on the display.
Intuitive buttons and layout
The symbols are for frequently used keys.
Cross-keys provide better operability.
Inside/outside
-
June 19, 2025
ABS Digimatic Height Gage Series 570
The New Standard in Smart and Reliable Height Measurement
Feature
Maximum permissible error EMPE : ±0.03 mm, ±0.05 mm, ±0.0015 in/±0.03 mm,±0.0020 in/±0.05 mm
Measuring range : 0 to 300 mm,0 to 600 mm,0 to 12 in/0 to 300 mm, 0 to 18 in/0 to 450 mm, 0 to 24 in/0 to 600 mm
Resolution : 0.01 mm,0.0005 in/0.01 mm
Functions : ON/OFF, ORIGIN, ZERO/ABS, HOLD/DATA, inch/mm conversion*
Drive method : Slider-feed wheel (manual)
Data output : DIGIMATIC d1
Max. response speed : Unlimited
LCD character height : 12 mm
Helps transform manufacturing sites into smart factories
The design of the case allows for easy installation of U-WAVE (optional), which enables wireless transmission of measurement data, promoting smarter use of data in manufacturing sites.
Supports smooth and reliable measurement operations
The handle for moving the slider enables smooth vertical movement. In addition, the highly rigid pillars and large clamp levers
-
June 19, 2025
High-Accuracy Height Gage Linear Height LH-600F/FG
high-precision 2D linear height gauge for complex work provides high precision up to ± (1.1+0.6L/600) μm
Easy operation using keypad and touch screen navigation, even suitable for beginners
Conduct various measurements such as 2D measurement and perpendicularity measurement with just one tool
Versatile measurements through optional probes
Enhanced data output functions make it easier to manage your measurement data
Easy operation using keypad and touch screen navigation
Contextual guidance on the large-screen touch panel supports your measurements
Simple, straightforward keys with icons
Icons allow the user to find the required operation at a glance.Touch panel with guidance
Measurement guidance is displayed on the large touch panel of the 8.4-inch color LCD, enabling intuitive operation.Fantastic features for shop-floor use
Automatic scale check
On start up, the user is led through the menu to set the scale origin and run
