Ultra-deep fine-hole drills for high-hardened steel : EMSBHE-ATH

“From small hole EDM to drilling”
This marks the next step in the evolution of the Epoch Micro Step Borer H.
A total of 124 products ideal for various types of pin hole drilling

Do you have problems with EDM for deep, small-diameter pin holes?

EMSBHE-ATH

Features of EMSBHE-ATH

Specially designed for micro-step drilling of deep, high-precision

HGOS-PN / HGOB(LS)-PN  Epoch Panacea series

New coating with amazing adhesion and wear resistance

Features of PN Coating

1.  A heat-resistant coating material with excellent adhesion to the tool substrate was achieved by optimizing the Al content.

2.Exhibits with good wear resistance due to Si doping to the AlCr coating layer

3.Exhibits excellent cutting life for cutting materials such as plastic molds, etc. where tool seizure often occurs. (2x the cutting life compared to conventional products.) Provides the long life in cutting processing of materials starting with HPM-MAGIC and including prehardened steel, carbon steel, alloy steel, SUS, SKD61, SKD11, etc.

4.By improving heat resistance, long life are possible for both wet cutting and dry cutting.

 Note) This product obtains less electric conductivity. Therefore, Please caution of using electric transmitted measuring systems.

ไมโครมิเตอร์ดิจิตอล ความเร็ว และความแม่นยำสูง

QuantuMike

ลดเวลาในการทำงาน และเพิ่มการผลิตชิ้นงานได้มากขึ้น

ใช้สกรูตะกั่วขนาด 2.0 มม. ช่วยลดเวลาในการขยับเข้าใกล้ชิ้นงานได้ประมาณ 60% นอกจากนี้ เวลาในการปล่อยชิ้นงานยังสั้นลงด้วย ทำให้สามารถลดเวลาในการวัดชิ้นงานที่มีหลายขั้นตอนได้อย่างมาก รุ่นนี้ได้รับการออกแบบมาเพื่อให้ใช้งานได้ง่ายในสถานที่ทำงานต่างๆ

ความเร็วสูง & ความแม่นยำสูง

Contour and Surface Roughness Measuring Systems FORMTRACER Avant Series

FORMTRACER Avant SERIES
Contour and Surface Roughness Measur ing Systems

Speed and operability like never before
A revolutionary measuring system that defies conventional thinking.

The hybrid measuring system “FORMTRACER Avant Series" allows for measurements of both contour and surface roughness features. Equipped with “speed” enabling higher measurement efficiency, “operability” with automation and a wide variety of features, and expandability which offers upgrading to a complex system by incorporating optional detectors, this revolutionary measuring system defies conventional thinking.

ดอกเอ็นมิลสำหรับกัดเหล็กแข็ง ซึ่งสามารถกัดเหล็กแข็งได้สูงถึง 72 HRC รุ่น EPDBEH-TH3

เปลี่ยนทุกความท้าทายในการกัดเหล็กชุบแข็ง... ให้กลายเป็นเรื่องง่าย ด้วยดอกเอ็นมิล EPDBEH-TH3 จาก MOLDINO

จุดเด่นที่คุณไม่ควรพลาด:

- พิชิตเหล็กแข็งได้อย่างมั่นใจ รองรับวัสดุเหล็กแข็งระดับ 60 HRC และสามารถรองรับการกัดเหล็กแข็งได้สูงถึง 72 HRC เช่น:
  • เหล็กกล้าชุบแข็ง (Hardened Steel)
  • เหล็กกล้าเครื่องมือ (Tool Steel)
  • เหล็กกล้าดาย (Die Steel)
  • เหล็กกล้าแม่พิมพ์ (Mold Steel)

- ความเร็วสูง | ความแม่นยำสูง:
  • ใช้รอบตัดได้เร็วโดยไม่เสียคุณภาพผิว
  • ลดการสั่นสะเทือน ด้วยโครงสร้างคอสั้น แข็งแรงแบบ Strong Neck
  • เหมาะกับงานละเอียดที่ต้องการความเที่ยงตรงสูง

พลังแห่งนวัตกรรม: TH3 Coating

การเคลือบผิวระดับพรีเมียมเพื่อ "งานกัดเหล็กแข็ง" โดยเฉพาะ

VIO SERIES – EQUIPMENT AND FUNCTIONALITY

VIO linear – maximum ease of use and functionality

Optimize process reliability in your production with fully automatic measurement capabilities. The open device platform allows for the integration of both new and existing production processes.

Maximum stability and precision
The FEM-optimized, thermally stable cast iron construction of the VIO linear series ensures accurate measuring results and equipment longevity. Additionally, highly dynamic, wear-free linear drives ensure accurate long-term quality. The parallel drive and guidance system ensures optimal distribution of forces and guarantees ±2 µm measurement repeatability.

Highlights
– High rigidity ensures low distortion even at the maximum permissible load
– FEM-optimized and thermally stable cast iron construction
– Maximum tool weight 352 lbs (160 kg)
– Fast, silent and highly accurate cutting edge approach via unique linear drive

Projector PH/PJ/PV Series

Each Mitutoyo profile projector is a measuring machine that performs measurements, inspections, and observations efficiently by projecting an image of a test workpiece on the stage onto a viewing screen under accurate magnification.The inherently non-contact measurement method of profile projectors makes this type of instrument highly suitable for measuring small parts that are unmeasurable with general-purpose contact instruments along with easily deformed plastic parts. Profile projectors can also be used to observe the surface profiles of workpieces or inspect minute assemblies with surface illumination. Additionally, a wide selection of accessories allows for measurement and inspection of various workpieces.These machines can be installed and used in a wide range of environments from inspection rooms to manufacturing and processing sites.

Provides reliable measurements in manufacturing site environments.

Does YAMAWA produce and sell specific taps for STI (Screw Thread Insert) like the brand name "Helisert" or Helicoil?

"Helisert" is a brand name of the helical coil wire manufactured in India and used throughout Asia. "Helicoil" is the brand name of the helical wire manufactured in the USA and used throughout North America. A helical coil wire is inserted into an internal screw thread to prevent damage and reinforce the original thread. Each manufacturer has its own brand name.

YAMAWA calls these "Helical Coil Wire Screw Thread Inserts". We produce and sell selective taps for this particular usage in a variety of tap series such as Hand Taps, Spiral Fluted Taps, Spiral Pointed Taps, and others.

High-performance ABS Digimatic Indicator ID-C/ID-F

New-generation ID series making measurement operations smoother and enhancing production quality

The first Mitutoyo measuring tools to support bidirectional serial communication. Dramatically improve work efficiency by connecting and linking with a PC.

High-Accuracy Digimatic Micrometer MDH-25MB

MDH-25MB

Easy, Rapid and High-accuracy Measurement of Workpieces That Require an Accuracy of 1 μm or Less

Delivering a Maximum Permissible Error JMPE of ±0.5 μm accuracy at 0.1 μm resolution means Mitutoyo's MDH-25MB is the most accurate digital micrometer available*, and this instrument will enable you to easily and
rapidly measure workpieces that require very-high-accuracy measurement. This remarkable performance has been attained thanks to Mitutoyo's proprietary ABS (absolute) rotary encoder and high-accuracy thread cutting technology.

APPLICATION

Beyond the Usual Micrometer! Many More Kinds of High-accuracy Parts Now Measurable.

This micrometer allows easy, rapid and high-accuracy measurement of workpieces that require a measuring accuracy of 1 μm or less, such as medical parts, precision instruments and auto-parts regarded as difficult to be accurately measured with conventional micrometers.
