Portable Surface Roughness Tester

Surftest SJ-310 Series

More than 20 years from the launch of the SJ Series! They have been pioneers of compact surface roughness testers. With overwhelming performance, they contribute to manufacturing all over the world.

SJ-310 Series  Other Functions

MiSCAN Vision System

A thoroughbred microscopic-form measurement system, developed from coordinate measuring machine and vision measurement system technology

Highly accurate autonomous scanning covering from micro-form to large workpieces

Newly developed MPP-NANO probe on which styli as small as 125 µm diameter can be mounted achieves autonomous scanning of fine detail.Using the observation camera, the approach to the workpiece can be easily performed while also checking for dirt and scratches on the workpiece. The highly proven SP25M scanning probe is also supported so the system can also be used for large workpieces as well as small.

Vision measurement functions provide high level performance

Uses the same image head as the Quick Vision series, the best-selling vision measuring system. Also equipped with the same optical system as the Quick Vision, multiple lighting functions and excellent evaluation software to provide high performance.

Measuring machine well suited to micro-form

QUICK SCOPE QS-L

Height measurement now available from one machine

High-speed image auto focus achieving height measurement now standard equipment. Measurements thus far performed separately using an optical measuring instrument and an indicator are now integrated into one machine.

Reliable small-parts measurement

High-speed 7X optical zoom with an interchangeable objective lens unit provides sharp and bright images. Measures details that cannot even be recognized when using digital zoom.

Highlights hard-to-see edges

High-intensity 4-quadrant LED ring light generates shadows to highlight edges that otherwise would be practically invisible.

Problems with simple dimensional measuring devices

CNC Coordinate Measuring Machine MiSTAR 555

MiSTAR 555

Highly Environment-resistant Coordinate Measuring Machine,Allowing near-line or in-line inspection.

MiSTAR 555 is a CNC coordinate measuring machine conceived to be a “measuring machine for any environment”. Wide accuracy-guaranteed temperature range, environment-resistant absolute scale, and all-in-one space-saving design. With performance that sets it apart from conventional coordinate measuring machines, MiSTAR 555 will boost your productivity.

Environment

Making measurements in harsh shop floor environments possible.

With an environment-resistant absolute scale*1 and revamped body structure, MiSTAR 555 is a contamination-resistant coordinate measuring machine. Highly reliable as a result of real-time temperature compensation technology that guarantees accuracy over a wide temperature range, it delivers a length measurement error of just E0, MPE of 2.2 + 3L/1000 μm*2. MiSTAR 555 can be installed and operated next to machine

ABS Digimatic Indicator ID-S Series

Simple, cost-effective and easy-to-use Digimatic Indicators. Choose long-life battery or everlasting solar powered models.

The ID-S series of ABS Digimatic indicators is made up of single-function type digital indicators: the ID-SS, which is the world’s first solar-powered Digimatic indicator, and the ID-SX, which is powered by a button-type battery.These Digimatic indicators have a measuring range of 12.7 mm, and indicators that can display resolutions of 0.01 mm and 0.001 mm are included in the lineup. For the ID-SX, some of models are available and provide IP53* dust/water protection level specifications. All the Digimatic indicators in this series are compact, with approximately the same size as a standard dial indicator. They employ large liquid crystal displays with character heights of 9 mm, and the large buttons are easy to press and make all the functions easy to operate. Furthermore, even though these models are priced competitively, the

CNC Coordinate Measuring Machine CRYSTA-Apex V Series

 CRYSTA-Apex VSERIES

Introducing generation CNC coordinate measuring machine focused on accuracy, speed, and versatility.

We are proud to unveil our CRYSTA-Apex V Series that delivers faster measurement of small- to  large sized parts without compromising the measuring machine’s inherent accuracy, and helps make the smart factory a reality.

A brand  CMM design that provides cutting-edge capability  in an extensive series of models that covers practically any measurement application in the small- to large sized part range.

The aesthetic design sports bold colours that befits a precision measuring instrument of the IoT age.Offering a choice of models for measuring from small to large sized workpieces, the CRYSTA-Apex V Series delivers advances in accuracy, speed and versatility in this class of CMM.

HIGH PRECISION

Projector PH/PJ/PV Series

Each Mitutoyo profile projector is a measuring machine that performs measurements, inspections, and observations efficiently by projecting an image of a test workpiece on the stage onto a viewing screen under accurate magnification.The inherently non-contact measurement method of profile projectors makes this type of instrument highly suitable for measuring small parts that are unmeasurable with general-purpose contact instruments along with easily deformed plastic parts. Profile projectors can also be used to observe the surface profiles of workpieces or inspect minute assemblies with surface illumination. Additionally, a wide selection of accessories allows for measurement and inspection of various workpieces.These machines can be installed and used in a wide range of environments from inspection rooms to manufacturing and processing sites.

Provides reliable measurements in manufacturing site environments.

High-performance ABS Digimatic Indicator ID-C/ID-F

New-generation ID series making measurement operations smoother and enhancing production quality

The first Mitutoyo measuring tools to support bidirectional serial communication. Dramatically improve work efficiency by connecting and linking with a PC.

QM-Height Series - High-Performance Height Gage

This is a High-accuracy digital height gauge and multifunction measurement.

Features

• Best-in-class accuracy ±(2.4+2.1L/600) μm
• Built-in pneumatic flotation system enables smooth movement over a surface plate. Models without the air suspension feature are also available.
• Simple-to-use control panel enables most measurements to be made with a single keystroke.
• Battery life of 1200 hours in continuous use with four AA batteries, an improvement from 300 hours.
• Install the optional U-WAVE-T measurement data communication system to output measurement data directly to Excel or SPC software on your PC.

GO/±NG judgment by LED and display symbols

LEDs indicate tolerance judgment status – green for GO, red for +NG, and orange for -NG. Status is also indicated by corresponding symbols appearing on the display.

Intuitive buttons and layout

The symbols are for frequently used keys.

Cross-keys provide better operability.

Inside/outside

ABS Digimatic Height Gage Series 570

The New Standard in Smart and Reliable Height Measurement

Feature

Maximum permissible error EMPE :  ±0.03 mm, ±0.05 mm, ±0.0015 in/±0.03 mm,±0.0020 in/±0.05 mm

Measuring range :  0 to 300 mm,0 to 600 mm,0 to 12 in/0 to 300 mm, 0 to 18 in/0 to 450 mm, 0 to 24 in/0 to 600 mm

Resolution :  0.01 mm,0.0005 in/0.01 mm

Functions :  ON/OFF, ORIGIN, ZERO/ABS, HOLD/DATA, inch/mm conversion*

Drive method :  Slider-feed wheel (manual)

Data output :  DIGIMATIC d1

Max. response speed : Unlimited

LCD character height :  12 mm

Helps transform manufacturing sites into smart factories

The design of the case allows for easy installation of U-WAVE (optional), which enables wireless transmission of measurement data, promoting smarter use of data in manufacturing sites.

Supports smooth and reliable measurement operations

The handle for moving the slider enables smooth vertical movement. In addition, the highly rigid pillars and large clamp levers
